5.6.1.
Implementing IP Security
The RPC-4840N can be configured to restrict unauthorized IP
addresses from Telneting to the unit. This allows the user to
grant Telnet access to only a specific group of IP addresses, or
block a particular IP address from gaining access. In the default
state, the RPC accepts incoming IP connections from all hosts.
To configure the IP Security feature, proceed as follows:
1. Access the Network Parameters menu as described in
Section 5.6. Note that the Network Parameters menu is
not available in User Mode.
2. When the Network Parameters menu appears, type 4 and
press [Enter] to access the IP Security menu (Figure 5.6).
3. The IP Security menu lists five IP Security "masks" along
with the selected permit/deny action for each mask.
a) Each Security Mask prompt is used to define a specific
IP address or range of IP addresses. Each Mask Action
prompt is used to define the permit/deny action for the
corresponding Mask.
b) Masks are listed in order of ascending priority; Mask 1
has the lowest priority, Mask 5 has the highest priority.
c) Masks have a cumulative effect; high priority masks
supersede the effect of lower priority masks.
d) Each IP Address consists of a series of four eight bit
numbers. The number 255 is used as a wild card.
5-10
RPC-4840N Remote Power Controller; User's Guide
IP SECURITY
1.
Security Mask #1:
(undefined)
2.
Mask #1 Action:
Permit
3.
Security Mask #2:
(undefined)
4.
Mask #2 Action:
Permit
5.
Security Mask #3:
(undefined)
6.
Mask #3 Action:
Permit
7.
Security Mask #4:
(undefined)
8.
Mask #4 Action:
Permit
9.
Security Mask #5:
(undefined)
10.
Mask #5 Action:
Permit
Enter Selection or
Figure 5.6: IP Security Menu
