4.2. Option Switches

The Option Switches select default settings for the Baud Rate,

Command Echo, Boot Delay and Disconnect Timeout. Default

settings selected via the Option Switches will be used when the

unit is reset to default parameters as described in Section 4.3.

Notes:

Although the Option Switches select default

settings for these features, the RPC-4840N

configuration menus can also be used to select

operating parameters as described in Section 5.

If Option Switch settings are changed, the new

settings will not be applied until the unit is reset

as described in Section 4.3.

Option Switch settings are described below:
Baud Rate: The default baud rate for both the Console Port and

Modem Port.

Boot Delay: The default Boot Delay setting. When a boot cycle

is initiated, the Boot Delay determines the length of time each

switched circuit will remain off until power is restored.

Command Echo: The default setting for the Command Echo for

the Console Port, Modem Port and Network Port. When

enabled, commands entered at your keyboard will be sent to

the RPC and echoed back to your display monitor.

Disconnect Timeout: The default Disconnect Timeout value.

This determines how long the RPC will wait for additional

commands before automatically disconnecting. Note that

when the RPC times out, DTR will drop, and the modem

disconnect and initialize strings will be sent.

Switch Function

Up

Down

1

Default Baud Rate

38.4K bps 9600 bps*

2

Default Boot Delay

10 Sec.

5 Sec.*

3

Default Command Echo

Enable

Disable*

4

Default Disconnect Timeout

30 Min

2 Min*

* = Factory Setting

4-2

RPC-4840N Remote Power Controller; User's Guide
