Telephone settings
Base unit layout
3
4
8
7
6
9
10 11
12
13
17
15
16
5
2
1
18
14
1. LCD dsplay
2. Softkeys
3. SPEAKERPHONE
4. DELETE
5. REPEAT
6. PLAY/STOP
7. SKIP
8. CLEAR
9. VOLUME
10. INTERCOM
11. New message LED
12. Antenna
13. Chargng LED
14. Speaker
15. Mcrophone
16. Telephone jack
17. DC connector jack
18. Spare battery
compartment
