38
• S Speaker (Surround Left and Right Speakers)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to select the parameter.
Choices: Large, Small, and None
Large - If you have large surround left and right speakers.
Small - Select this position if your surround left and right
speakers do not have a high ability for bass reproduction.
In this position, low bass signals (100 Hz) in the surround
left and right channels are output from the subwoofer
speaker, or from the left and right main speaker if the
subwoofer setting is set to the “N (none)” position.
None - Select this position if your system does not include
the surround left and right speakers. The surround left
and right channels will be output from the front left and
right speakers instead.
• B Speaker (Back Surround Speakers)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to select the parameter.
Choices: 0/0, S/0, L/0, S/S, and L/L
0/0 - When there are no back speakers
S/O - When there is only one small back speaker
L/0 - When there is only one large back speaker
S/S - When there are two small back speakers
L/L - When there are two large back speakers
• SW Speaker (Subwoofer)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to select the parameter.
Choices: Y (yes), N (none)
Y (Yes) - If your system includes a subwoofer.
N (None) - If your system does not include a subwoofer
Adjusting Speaker Output Levels
• FL VOL (Front Left Channel level)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to adjust the level.
Level range: -10dB to +10dB
1. Turn the Input/Adjust knob on the front panel clock-
wise or press the button on the remote control to
raise the level.
2. Turn the Input/Adjust knob on the front panel counter-
clockwise or press the button on the remote control to
lower the level.
• FR VOL (Front Right Channel level)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to adjust the level.
Level range: -10dB to +10dB
1. Turn the Input/Adjust knob on the front panel clock-
wise or press the button on the remote control to
raise the level.
2. Turn the Input/Adjust knob on the front panel counter-
clockwise or press the button on the remote control to
lower the level.
• LB VOL (Left Back Surround Channel level)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to adjust the level.
Level range: -10dB to +10dB
1. Turn the Input/Adjust knob on the front panel clock-
wise or press the button on the remote control to
raise the level.
2. Turn the Input/Adjust knob on the front panel counter-
clockwise or press the button on the remote control to
lower the level.
• RB VOL (Right Back Surround Channel level)
Use the Input/Adjust knob on the front panel or the and
buttons on the remote control to adjust the level.
Level range: -10dB to +10dB
1. Turn the Input/Adjust knob on the front panel clock-
wise or press the button on the remote control to
raise the level.
2. Turn the Input/Adjust knob on the front panel counter-
clockwise or press the button on the remote control to
lower the level.
Speaker Settings Menu cont.
