A - 2 – TurboChef Technologies 2020 User Manual
Page 66

A - 2
Part Details...
Locate the Part Here...
Item
Part Number
Qty. Per Oven
Outside of
End Bells
(Page A-4)
Left End Bell
(Page A-6)
Right End Bell
(Page A-8)
Heater Cover
HCT-4032
1
Jetplate
HCT-4099
2
Keypad
HHC-1234
1
Leg
100785
4
Plenum
HCT-4020
2
Power Cord
HCT-4116-3 (NEMA
15-50P) or
HCT-4116-2
(IEC60309)
1
Power Cord Retainer
I5-9211
2
Power Supply
101211
1
Power Supply Bracket
HCT-4103
1
Relay, Mechanical, K6
101279
1
Relay, Mechanical, K7
101279
1
Relay, Solid State, K4/K5
NGC-3005
1
RTD
HHC-6517-2
1
Shelf Tray (Crumb Tray Extension)
HCT-4050
2
Smart Card Reader
100506
1
Speaker
104155
1
Support, Top Plenum
HCT-4169
1
Thermostat, Cooling Fan
102086
2
Thermostat, High Limit
102075
1
Voltage Sensor
100783
1
Wire Harness, EMI to Fan Control, Conveyor
Control
HCT-4086-7
1
Wire Harness, EMI to Fan Control, Power
Supply, Conveyor Control
HCT-4086-5
1
Wire Harness, Fuse Block to EMI
HCT-4086-6
1
Wire Harness, Fuse Block to High Limit
HCT-4086-3
1
Wire Harness, Fuse Block to SSR, 4" LG
HCT-4086-9
1
Wire Harness, Fuse Block to SSR, 4.25" LG
HCT-4086-8
1
Wire Harness, High Limit to Distribution
Block
HCT-4086-4
1
Wire Harness, High Voltage, Main
HCT-4086-1
1
Wire Harness, LOV
HCT-4163-1
1
Wire Harness, SSR to Distribution Block
HCT-4086-2
1
A P P E N D I X - R E P L AC I N G O V E N CO M P O N E N T S
