Replacing Oven Components
WARNING: Before removing or replacing any oven component, thoroughly read the safety
instructions found at the front of this manual and
Oven Systems (pages 21-24). Adhere to
all precautions and warnings outlined in these sections, as failure to do so could result in
serious injury or death.
Part Details...
Locate the Part Here...
Item
Part Number
Qty. Per Oven
Outside of
End Bells
(Page A-4)
Left End Bell
(Page A-6)
Right End Bell
(Page A-8)
Air Filter
HCT-4067
2
Back Panel
HCT-4105
2
Blower Motor Assembly
HCT-4205
2
Blower Motor Controller
100443
2
Blower Wheel
104107
2
Cable, Display, Power, 2-Pin
100193
1
Cable, Display, Ribbon
100184
1
Cable, Smart Card Reader
100182
1
Chain, Conveyor
HCT-4143
1
Chainguard, Left (Split-belt config only)
HCT-4038
1
Chainguard, Right
HCT-4041
1
Channel
HCT-4076
1
Control Board
CON-7002
1
Conveyor Controller
HHC-6630-2
2
Conveyor Motor
HCT-4120
2*
Conveyor (Single Belt)
HCT-4140
1
Conveyor (Split Belt 50/50)
HCT-4096
1
Conveyor (Split Belt 70/30)
HCT-4115
1
Cooling Fan
TC3-0433
2
Crumb Tray
HCT-4045
2
Display, VFD
NGC-3023
1
Distribution Block
HCT-4141
1
EMI Filter
100539
2
Eyelid
HCT-4028
2
Finger Guard
100086
2
Fuse, 20 Amp, Class CC
100599
2
Fuse Block
103548
1
Gear Motor Cover (Single-belt config only)
HCT-4142
1
Hanger
HCT-4148
1
Hatch
HCT-4209
1
Hatch Latch
100777
2
Heat Slinger
102708
2
Heater, Back
HCT-4161
1
Heater, Front
HCT-4162
1
* Quantities will differ depending on conveyor type.
