2 2

O V E N S YS T E M S

Testing Procedure

1. Disconnect line voltage to the unit.

2. Take a resistance reading of the coil.

3. If coil resistance is correct (585

W

):

a) Apply line voltage to the unit.

b) Check for 24 VDC at the coil of the

relay when the unit is calling for heat.

c) Check the state of the contacts.

-If the normally open contacts (7 & 4

-

or C & NO) are closed when coil

-

voltage is applied, the relay is

-

functioning normally.

-If the normally open contacts (7 & 4

-

or C & NO are not closed when coil

-

voltage is applied, the relay must be

replaced (page A-7 and A-8).

4. If the coil resistance is incorrect, replace the

relay.

Relay, Solid State - K5/K4 Heaters

The solid state relay is a 240 VAC, dual 40-amp
relay, and switches power to the heaters.

RTD

The RTD is a resistance temperature detector
used to detect the cavity temperature.

Testing Procedure

1. Disconnect the RTD from the I/O control

board.

2. Place the RTD in a bowl of ice water for 2

minutes.

3. Take a resistance reading of the RTD.

4. If RTD resistance is not 100

W

, RTD is

defective and must be replaced.

NOTE: Use Figure 32 to determine resistance
readings at temperatures other than freezing.

Smart Card Reader

The smart card reader allows the oven operator
to load a menu/firmware update from a smart
card. A menu that already exists in the oven can
also be saved to a smart card. For instructions,
see page 15.

Speaker

The speaker is separate from the control board,
and provides audible feedback to the oven oper-
ator whenever a key is pressed or a fault occurs.

Thermostats - 120ºF (Close on Rise)

The cooling fan thermostats actuate the cooling
fans when the temperature in either end bell
reaches or exceeds 120ºF (49ºC).

Wire Harness

The wire harness distributes power to the oven’s
electrical components. See pages 37-40 for
schematics.

ºF

+20º

+40º

+60º

+80º

+100º

+120º

+140º

+160º

+180º

+200º

90.03

W

97.39

W

101.74

W

106.07

W

110.38

W

114.68

W

118.97

W

123.24

W

127.50

W

131.74

W

135.97

W

+200º

135.97

W

140.18

W

144.38

W

148.57

W

152.74

W

159.90

W

161.04

W

165.17

W

169.29

W

173.39

W

177.47

W

+400º

177.47

W

181.54

W

185.60

W

189.64

W

193.67

W

197.69

W

201.69

W

205.67

W

209.64

W

213.60

W

217.54

W

+600º

217.54

W

221.47

W

225.38

W

229.28

W

233.17

W

237.04

W

240.90

W

244.74

W

248.57

W

252.38

W

256.18

W

ºC

+10º

+20º

+30º

+40º

+50º

+60º

+70º

+80º

+90º

+100º

100.00

W

103.90

W

107.79

W

111.67

W

115.54

W

119.40

W

123.24

W

127.07

W

130.89

W

134.70

W

138.50

W

+100º

138.50

W

142.29

W

146.06

W

149.82

W

153.58

W

157.31

W

161.04

W

164.76

W

168.46

W

172.16

W

175.84

W

+200º

175.84

W

175.91

W

183.17

W

186.82

W

190.45

W

194.07

W

197.69

W

201.29

W

204.88

W

208.45

W

212.02

W

+300º

212.02

W

215.57

W

219.12

W

222.65

W

226.17

W

229.67

W

233.17

W

236.65

W

240.13

W

243.59

W

247.04

W

Figure 32: Temperature/Resistance Relationship Class B. Resistance @ 0ºC = 100.0, Alpha = 0.003850
