SZX16
CONTENTS
IMPORTANT
— Be sure to read this section for safe use of the equipment. —
1
NOMENCLATURE
2
CONTROLS
3
SUMMARY OF OBSERVATION PROCEDURE
4
USING THE CONTROLS
1-3
4
5
6
7-13
4-1 Base ...................................................................................................................................................................................................................... 7
1
Using the Stage Plate
2
Placing the Specimen
4-2 Microscope Body and Focusing Assembly ......................................................................................... 7-9
1
Adjusting the Tension of the Coarse Focus Adjustment Knob
2
Engaging and Disengaging the Zooming Knob Click Stop Function
3
Adjusting the Aperture Iris Diaphragm
4
Zoom Magnification Indication
5
2X Objective Correction Collar
4-3 Observation Tube .................................................................................................................................................................. 10-12
1
Adjusting the Interpupillary Distance
2
Adjusting the Diopter (Zoom Parfocal Adjustment)
3
Using the Eye Shades
4
Using the Eyepiece Micrometer Disk
5
Selecting the Light Path
6
Adjusting the Tilt
4-4 TV Observation and Photomicrography ........................................................................................................ 13
1
Selecting the TV Adapter Magnification
2
Mounting the TV Adapter
3
Selecting the TV Camera Light Path
6
SPECIFICATIONS
7
OBSERVATION MAGNIFICATIONS AND OBSERVATION AREAS
5
TROUBLESHOOTING GUIDE
14
15,16
17
