28
OPTION MENU
ITEM SETTING FUNCTION
RESET ALL -------------------------------- Pressing the ENTER button shows a confirmation box.
Select “Yes” and press ENTER button. Then, the
settings that were made in the picture quality setting
menu and the professional-use picture quality setting
menu are changed to the factory-default settings.
AUTO OFF ------------- 0 ---------------- Auto power off does not function.
10-90 MINUTES --------- Without a picture image signal input, the power is
automatically turned off at the preset time.
LAMP HOUR ------------------------------- Indicates used-hours of the lamp. It is not possible to
change the indicated used-hours.
INSTALLATION MENU
ITEM SETTING FUNCTION
LANGUAGE -------------------------------- Selects a language used for displays on the screen,
such as menus.
RGB & COMPONENT ------------------- Adjusts computer video images.
AUTO * ------------------------------------ Selecting Auto and pressing the ENTER button
automatically adjust position and size of the projected
images in accordance with the image signals from the
computer.
FREQUENCY * - -15 ~ +15 ---------- If any wide streak pattern appears on the projected
images, it can be adjusted with this setting while
viewing the images.
PHASE * ------------ 0 ~ +31 ----------- If any flicker or blur appears on the projected images,
it can be adjusted with this setting while viewing the
images.
H.POS * ---------- -30 ~ +30 ---------- Moves display position of projected images in a
horizontal direction.
V. POS * ------------ -30 ~ +30 ---------- Moves display position of projected images in a vertical
direction.
MIRROR ------- FLOOR FRONT ------ Select this setting with the projector set on the floor
when viewing the projected images from the front side.
Normally, select this setting.
CEILING FRONT ----- Select this setting with the projector suspended from
the ceiling when viewing the projected images from
the front side.
FLOOR REAR ------- Select this setting with the projector set on the floor
when viewing the projected images from the rear side
of the screen.
CEILING REAR ------ Select this setting with the projector suspended from
the ceiling when viewing the projected images from
the rear side of the screen.
KEYSTONE ------- -12 ~ +12 ---------- Select this setting when correcting trapezoidal
distortion. Normally, select “0”.
PATTERN ---------------------------------- Pressing ENTER button reveals the test pattern for
focus adjustment.
• The items with the * mark function only for 1080i, 720p, 525p, and 625p input signals and input signals from DVI terminal.
• The varying range of the vertical position depends on the type of the input signal. With some values the vertical position
may not change, but this is not a malfunction.
• With the inputs from DVI-DIGITAL terminal, no change appear on the projected images with adjustment of the dividing
ratio and fine, but this is not a malfunction.
• Without input signals, only some of the above items can be changed.
• Contact your dealer for the ceiling mount bracket. As installation requires technical knowledge and skill, be sure to ask your
dealer for installation.
• When mounted on the ceiling, the product shall be installed by the dealer with the bracket designed for this product. If you
attempt to install the product by yourself, you may fall and be injured or the product may fall causing injury.
INSTALLATION...
RGB & COMPONENT
MIRROR
KEYSTONE
PATTERN
LANGUAGE
RGB & COMPONENT
FREQUENTCY
AUTO YES?
PHASE
H. POS
V. POS
0
15
0
0
RGB & COMPONENT MENU
USING THE MENUS
RESET ALL
AUTO OFF
LAMP HOUR
ENTER
0
+11
MINUTES
HOURS
OPTION...
