Transcend Information III User Manual
Page 21
Connecting to the Network
2-7
The next step is to load the drivers, as explained in Chapter 3.
If you are running Windows 95, you can confirm the network
connection by double-clicking the Network Neighborhood
icon. The presence of the Entire Network icon in the display
box confirms the network connection.
Figure 2-4 Slide Latch
.
Figure 2-5 Connecting the AUI Cable
Closed
AUI
connector
Slide latch
Open
AUI
cable
BNC
connector
AUI
connector
RJ-45
connector
