– 46 –
8-3.
Indoor Print Cir
cuit Boar
d
4-W
a
y Air Disc
har
g
e Cassette
T
ype
RA
V
-SM560UT
-E/RA
V
-SM800UT
-E
Microcomputer operation LED
EEPROM
Network adapter
power supply Indoor/Outdoor
inter-unit cable
Remote controller power LED
Drain pump output
Remote controller inter-unit cable
EXCT Outside error input
TC sensor
TCJ sensor
DISP
CHK
TA sensor
Optional output
Louver
Float SW
DC fan return
DC fan output
