Replaceable Mechanical Parts
10–4 WFM 300A
Replaceable Mechanical Parts
Fig. &
Index
No.
Tektronix
Part No. Serial Number
Effective Dscont
Qty
12345 Name & Description Mfr.
Code
Mfr. Part No.
1–1 426–2174–00 1 FRAME,CRT:BEZEL
*MOUNTING PARTS* TK1151 ORDER BY DESC
–2 211–0690–02 2 SCREW,MACHINE:6–32 X 0.875,PNH,SST
*END MOUNTING PARTS* 93907 B20–70430
–3 333–3397–00 1 PANEL,FRONT:WFM300 22670 ORDER BY DESC
–4 378–0298–00 1 FILTER,CRT:CLEAR,4.736 X 3.882,PLEXIGLASS 0JR05 378–0298–00
–5 354–0670–00 1 RING,RETAINING:COLOR SHUTTER TK1151 ORDER BY DESC
–6 348–0660–00 4 CUSHION,CRT:POLYURETHANE 80009 348066000
–7 333–3761–01 1 PANEL,FRONT:WFM300A
*MOUNTING PARTS* 80009 333376101
–8 211–0721–00 2 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR
*END MOUNTING PARTS* 0KB01 ORDER BY DESC
–9 ––––––––––– 1 CIRCUIT BD ASSY:FRONT PANEL
(SEE A2 REPL)
*MOUNTING PARTS*
–10 211–0721–00 3 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR
*END MOUNTING PARTS* 0KB01 ORDER BY DESC
–11 ––––––––––– 1 SWITCH,PUSH:0.4A,125VAC,W/SOLDER LUG,BUTTON
W/YELLOW INDICATOR
(SEE S1 REPL)
*MOUNTING PARTS*
–12 210–0405–00 2 NUT,PLAIN,HEX:2–56 X 0.188,BRS CD PL 73743 12157–50
–13 211–0100–00 2 SCREW,MACHINE:2–56 X 0.750,PNH,STL
*END MOUNTING PARTS* TK0435 ORDER BY DESC
–14 426–2101–01 1 FRAME SECT,CAB.:FRONT
*MOUNTING PARTS* TK1151 ORDER BY DESC
–15 211–0721–00 3 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR
*END MOUNTING PARTS* 0KB01 ORDER BY DESC
–16 ––––––––––– 1 CIRCUIT BD ASSY:MAIN
(SEE A3 REPL)
*MOUNTING PARTS*
–17 211–0721–00 8 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR
*END MOUNTING PARTS* 0KB01 ORDER BY DESC
–18 ––––––––––– 1 CIRCUIT BD ASSY:TRANSCODER STD
(SEE A3A1 REPL)
–19 ––––––––––– 1 CIRCUIT BD ASSY:GRATICULE LIGHT
(SEE A3A2 REPL)
–20 337–3375–01 1 SHIELD,ELEC:CIRCUIT BD,POLYCARBONATE 85471 337–3375–01
–21 ––––––––––– 1 CIRCUIT BD ASSY:POWER SUPPLY
(SEE A1 REPL)
*MOUNTING PARTS*
–22 211–0721–00 7 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR 0KB01 ORDER BY DESC
–23 210–0586–00 2 NUT,PL,ASSEM WA:4–40 X 0.25,STL CD PL TK0435 ORDER BY DESC
–24 211–0016–00 2 SCREW,MACHINE:4–40 X 0.625,PNH,STL
*END MOUNTING PARTS* TK0435 ORDER BY DESC
–25 131–3573–00 1 CONN,PLUG,ELEC:MALE,W/LOCKING ADAPTER 80126 B–0779
–26 337–3257–00 2 SHIELD,CKT BD:LV PWR SUPPLY 2K262 ORDER BY DESC
–27 337–3931–00 1 SHIELD,ELEC:ALUMINUM 80009 337393100
–28 175–9872–01 1 CA ASSY,SP,ELEC:2,18 AWG,2.5 L,0–N TK2364 175–9872–01
–29 333–3769–01 1 PANEL,REAR:WFM300A
*MOUNTING PARTS* 80009 333376901
–30 211–0721–00 2 SCREW,MACH:6–32 X 0.375,PNH,STL,CDPL,T–15 TORX DR
*END MOUNTING PARTS* 0KB01 ORDER BY DESC
–31 ––––––––––– 1 CIRCUIT BD ASSY:GBR
(SEE A5 REPL)
*MOUNTING PARTS*
–32 220–0497–00 12 NUT,PLAIN,HEX:0.5–28 X 0.562 HEX,BRS CD PL 73743 ORDER BY DESC
