Tektronix WFM 300A - Manual (Page 160)

Replaceable Electrical Parts
8–22 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A3R562 322–3261–00 RES,FXD,FILM:5.11K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G5111FT
A3R564 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R565 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R566 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R567 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R568 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R569 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R570 322–3170–00 RES,FXD,FILM:576 OHM,1%,0.2W,TC=T0,SMALL BODY 91637 CCF50G576R0F
A3R571 322–3218–00 RES,FXD:METAL FILM;1.82K OHM,1%,0.2W,TC=100 91637 CCF501G18200F
A3R572 322–3066–00 RES,FXD:METAL FILM;47.5 OHM,1%,0.2W,TC=100 PPM 09969 CCF502G47R50F
A3R573 322–3314–00 RES,FXD:METAL FILM;18.2K OHM,1%,0.2W,TC=100 91637 CCF501G18201F
A3R574 322–3030–00 RES,FXD:METAL FILM;20 OHM,1%,0.2W,TC=100 PPM 91637 CCF50G20R00F
A3R575 322–3030–00 RES,FXD:METAL FILM;20 OHM,1%,0.2W,TC=100 PPM 91637 CCF50G20R00F
A3R576 322–3030–00 RES,FXD:METAL FILM;20 OHM,1%,0.2W,TC=100 PPM 91637 CCF50G20R00F
A3R577 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R578 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R579 322–3185–00 RES,FXD:METAL FILM;825 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G825ROF
A3R580 311–2232–00 RES,VAR,TRMR:CERMET;2K OHM,20%,0.5W,0.197 SQ,TOP
ADJUST
TK2073 GF06UT2 202 M L
A3R581 322–3066–00 RES,FXD:METAL FILM;47.5 OHM,1%,0.2W,TC=100 PPM 09969 CCF502G47R50F
A3R582 322–3205–00 RES,FXD,FILM:1.33K OHM,1%,0.2W,TC=T0 91637 CCF501G13300F
A3R583 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A3R584 311–2228–00 RES,VAR,TRMR:CERMET;200 OHM,20%,0.5W,0.197
SQ,TOP ADJUST
TK2073 GF06UT2 201 M L
A3R585 322–3311–00 RES,FXD,FILM:16.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 56845 CCF–50–2–1692F
A3R586 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R590 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R591 322–3273–00 RES,FXD:METAL FILM;6.81K OHM,1%,0.2W,TC=100 91637 CCF50–2–G68100F
A3R593 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R594 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R595 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R596 322–3210–00 RES,FXD:METAL FILM;1.5K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G15000F
A3R597 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R598 315–0106–00 RES,FXD,FILM:10M OHM,5%,0.25W TK1727 SFR25 2322–181–
A3R621 322–3367–00 RES,FXD,FILM:64.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2–G64901F
A3R622 322–3367–00 RES,FXD,FILM:64.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2–G64901F
A3R628 311–2348–00 RES,VAR,NONWW:PNL,25K OHM,10%,0.5WLINEAR 12697 CM45227
A3R628 366–0649–00 KNOB:GY,0.127 ID X 0.392 OD X 0.5 H 80009 366064900
A3R628 376–0051–01 CPLG,SHAFT,FLEX:0.127 ID X 0.375 OD,DELRIN TK2562 376–0051–01
A3R628 384–1065–00 EXTENSION SHAFT:3.485 L X 0.125 OD,AL 80009 384106500
A3R632 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A3R634 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R635 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R636 322–3030–00 RES,FXD:METAL FILM;20 OHM,1%,0.2W,TC=100 PPM 91637 CCF50G20R00F
A3R637 322–3066–00 RES,FXD:METAL FILM;47.5 OHM,1%,0.2W,TC=100 PPM 09969 CCF502G47R50F
A3R638 322–3266–00 RES,FXD,FILM:5.76K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G57600F
A3R639 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R640 322–3237–00 RES,FXD,FILM:2.87K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G28700F
A3R641 322–3266–00 RES,FXD,FILM:5.76K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G57600F
A3R642 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R643 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R644 322–3126–00 RES,FXD,FILM:200 OHM,1%,0.2W,TC=T0MI,SMALLBODY 91637 CCF501G200ROF
A3R645 322–3246–00 RES,FXD,FILM:3.57K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G35700F
A3R646 322–3281–00 RES,FXD:METAL FILM;8.25K OHM,1%,0.2W,TC=100 91637 CCF501G82500F
A3R647 322–3185–00 RES,FXD:METAL FILM;825 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G825ROF
A3R648 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R649 322–3189–00 RES,FXD,FILM:909 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G909FOR
A3R650 322–3268–00 RES,FXD,FILM:6.04K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G60400F
