Replaceable Electrical Parts
8–13 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
366–0616–00 PUSH BUTTON:0.585 X 0.3 X 0.150 7X318 ORDER BY DESC
*END ATTACHED PARTS*
A2S530 260–2300–00 SWITCH,SIG:SPST;PUSH,MOM,NO,W/GROUND TERM,
MANUAL INSERTION,100 GRAMS,SILVER,SEALED
34361 B3F1152
*ATTACHED PARTS*
366–0616–00 PUSH BUTTON:0.585 X 0.3 X 0.150 7X318 ORDER BY DESC
*END ATTACHED PARTS*
A2DS107 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS108 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS109 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS123 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS124 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS125 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS142 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS143 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS208 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS209 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS220 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS242 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS243 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS307 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS308 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS309 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS320 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS341 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS342 150–1163–00 DIODE,OPTO:LED;GRN,565NM,24MCD AT 20MA,45
DEGREE VIEW ANGLE,NON–DIFFUSED
50434 HLMP–1540 OPT 0
A2DS420 150–1238–00 DIODE,OPTO:LED;HIGH EFFIC RED,626NM,24MCD
AT 20MA,45 DEG VIEW ANGLE,HLMP–1340,T–1
50434 HLMP1340
A2DS421 150–1238–00 DIODE,OPTO:LED;HIGH EFFIC RED,626NM,24MCD
AT 20MA,45 DEG VIEW ANGLE,HLMP–1340,T–1
50434 HLMP1340
A3 672–0278–09 B020000 B024644 CIRCUIT BD ASSY:MAIN 80009 672027809
A3 672–0278–10 B024645 B024748 CIRCUIT BD ASSY:MAIN 80009 672027810
A3 672–0278–11 B024749 B024877 CIRCUIT BD ASSY:MAIN 80009 672027811
A3 672–0278–12 B024878 CIRCUIT BD ASSY:MAIN 80009 672027812
*ATTACHED PARTS*
131–3717–00 BUS,CONDUCTOR:PCB;MALE,STR,2 X 42,0.3 X0.1
LAYER,INSULATED,6 AMP
(QUANTITY 3) 65033 SM2098
337–0896–00 PLATE,ELEC SHLD:B SWEEP CKT BD TK1935 337–0896–00
337–1197–02 SHIELD,ELEC:CIRCUIT BD;2.300 X .400 IN TK1947 337–1197–02
