Tektronix WFM 300A - Manual (Page 144)

Replaceable Electrical Parts
8–6 WFM 300A
Replaceable Electrical Parts
Component
Number Tektronix
Part Number Serial / Assembly Number
Effective Discontinued
Name & Description
Mfr.
Code Mfr. Part
Number
A1 671–2890–01 B020000 B024268 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289001
A1 671–2890–02 B024269 B024313 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289002
A1 671–2890–03 B024314 B024395 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289003
A1 671–2890–04 B024396 B024478 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289004
A1 671–2890–05 B024479 B024603 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289005
A1 671–2890–06 B024604 B024877 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289006
A1 671–2890–07 B024878 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289007
A2 671–1354–00 CIRCUIT BD ASSY:FRONT PANEL 80009 671135400
A3 672–0278–09 B020000 B024644 CIRCUIT BD ASSY:MAIN 80009 672027809
A3 672–0278–10 B024645 B024748 CIRCUIT BD ASSY:MAIN 80009 672027810
A3 672–0278–11 B024749 B024877 CIRCUIT BD ASSY:MAIN 80009 672027811
A3 672–0278–12 B024878 CIRCUIT BD ASSY:MAIN 80009 672027812
A3A1 671–1365–00 CIRCUIT BD ASSY:TRANSCODER STD
(STANDARD ONLY)
80009 671136500
A3A1 671–1358–00 CIRCUIT BD ASSY:TRANSCODER OPT 10
(OPTION 10 ONLY)
80009 671135800
A3A2 671–1796–00 CIRCUIT BD ASSY:GRATICULE LIGHT 80009 671179600
A4 671–1357–02 B020000 B024324 CIRCUIT BD ASSY:CONTROL 80009 671135702
A4 671–1357–03 B024325 B024877 CIRCUIT BD ASSY:CONTROL 80009 671135703
A4 671–1357–04 B024878 CIRCUIT BD ASSY:CONTROL 80009 671135704
A5 671–1356–04 CIRCUIT BD ASSY:GBR 80009 671135604
A1 671–2890–01 B020000 B024268 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289001
A1 671–2890–02 B024269 B024313 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289002
A1 671–2890–03 B024314 B024395 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289003
A1 671–2890–04 B024396 B024478 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289004
A1 671–2890–05 B024479 B024603 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289005
A1 671–2890–06 B024604 B024877 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289006
A1 671–2890–07 B024878 CIRCUIT BD ASSY:POWER SUPPLY 80009 671289007
A1C1 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A1C2 283–0021–00 CAP,FXD,CER DI:0.001UF,20%,5000V TK2058 TCK45YS3H102M–A
A1C3 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C4 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C5 285–1341–01 CAP,FXD,PLSTC:MTLZD FILM;0.1UF,20%,100V,POLYESTER TK1913 MKS 2 0.1UF 20%
A1C6 281–0771–00 CAP,FXD,CER DI:2200PF,20%,200V 04222 SA102C222MAA
A1C7 285–1470–00 CAP,FXD,PLMTLZDSTC:FILM;330PF,1600VDC/500VAC,POLY-
PROPYLENE,11 X18
TK1913 FKP1 330/1600/5
A1C8 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C9 283–0261–00 CAP,FXD,CER DI:0.01UF,20%,4000V 18796 DHR28Z5U103M4KV
A1C10 281–0563–00 CAP,FXD,CERAMIC:MLC;0.47UF,20%,50V,0.150 X0.290 04222 SA305E474MAA
A1C11 283–0021–00 CAP,FXD,CER DI:0.001UF,20%,5000V TK2058 TCK45YS3H102M–A
A1C12 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C13 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C14 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C15 285–1341–01 CAP,FXD,PLSTC:MTLZD FILM;0.1UF,20%,100V,POLYESTER TK1913 MKS 2 0.1UF 20%
A1C16 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A1C17 285–1341–01 CAP,FXD,PLSTC:MTLZD FILM;0.1UF,20%,100V,POLYESTER TK1913 MKS 2 0.1UF 20%
A1C18 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A1C19 290–1310–00 CAP,FXD,ALUM:10UF,20%,160V,ESR=24.9 OHM(120HZ,20C),
LS=0.200 INCH,13X20MM,105C,5000HRS
0H1N5 CEJSM2C100M
A1C20 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C21 281–0707–00 CAP,FXD,CER DI:15000PF,10%,200V 04222 MA302C153KAA
A1C22 281–0563–00 CAP,FXD,CERAMIC:MLC;0.47UF,20%,50V,0.150 X0.290 04222 SA305E474MAA
A1C23 285–1328–00 CAP,FXD,PLSTC:MTLZD FILM;0.01UF,5%,2000V,POLYPRO-
PYLENE,1.25X.95
TK1913 FKP1 .01/2000/5
