Replaceable Electrical Parts
8–19 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A3R225 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R239 322–3172–00 RES,FXD,FILM:604 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G604ROF
A3R242 322–3258–00 RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100 56845 CCF50–2–G4751FT
A3R243 322–3258–00 RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100 56845 CCF50–2–G4751FT
A3R253 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A3R254 322–3258–00 RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100 56845 CCF50–2–G4751FT
A3R255 315–0106–00 RES,FXD,FILM:10M OHM,5%,0.25W TK1727 SFR25 2322–181–
A3R257 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R258 322–3318–00 RES,FXD:METAL FILM;20K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20001F
A3R262 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R263 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R264 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R267 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A3R273 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A3R274 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A3R288 311–2232–00 RES,VAR,TRMR:CERMET;2K OHM,20%,0.5W,0.197 SQ,TOP
ADJUST
TK2073 GF06UT2 202 M L
A3R289 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R292 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R293 322–3123–00 RES,FXD:METAL FILM;187 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G187R0F
A3R295 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R297 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R314 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R315 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R316 322–3235–00 RES,FXD:METAL FILM;2.74K OHM,1%,0.2W,TC=100 91637 CCF501G27400F
A3R317 322–3235–00 RES,FXD:METAL FILM;2.74K OHM,1%,0.2W,TC=100 91637 CCF501G27400F
A3R318 322–3330–00 RES,FXD,FILM:26.7K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G26701F
A3R319 322–3330–00 RES,FXD,FILM:26.7K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G26701F
A3R329 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R333 322–3047–00 RES,FXD,FILM:30.1 OHM,1%,0.2W,TC=T0,SMALL BODY 57668 CRB20FXE30E1
A3R334 322–3047–00 RES,FXD,FILM:30.1 OHM,1%,0.2W,TC=T0,SMALL BODY 57668 CRB20FXE30E1
A3R343 322–3226–00 672–0278–09 672–0278–11 RES,FXD:METAL FILM;2.21K OHM,1%,0.2W,TC=100 91637 CCF501G22100F
A3R343 322–3266–00 672–0278–12 RES,FXD,FILM:5.76K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G57600F
A3R346 322–3172–00 RES,FXD,FILM:604 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G604ROF
A3R353 315–0106–00 RES,FXD,FILM:10M OHM,5%,0.25W TK1727 SFR25 2322–181–
A3R354 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R355 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R357 322–3297–00 RES,FXD:METAL FILM;12.1K OHM,1%,0.2W,TC=100 91637 CCF501G12101F
A3R358 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A3R359 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R359 337–0896–00 PLATE,ELEC SHLD:B SWEEP CKT BD TK1935 337–0896–00
A3R360 322–3318–00 RES,FXD:METAL FILM;20K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20001F
A3R361 322–3346–00 RES,FXD:METAL FILM;39.2K OHM,1%,0.2W,TC=100 91637 CCF50–2–G39201F
A3R362 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R363 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R364 322–3346–00 RES,FXD:METAL FILM;39.2K OHM,1%,0.2W,TC=100 91637 CCF50–2–G39201F
A3R365 311–2235–00 RES,VAR,TRMR:CERMET;10K OHM,20%,0.5W,0.197
SQ,TOP ADJUST
TK2073 GF06UT2 103 M L
A3R366 322–3269–02 RES,FXD,FILM:6.19K OHM,0.2W,5%TAPED & REELED 91637 CCF501D61900D
A3R370 322–3259–00 RES,FXD,FILM:4.87K OHM,1%,0.2W,TC=T0MI,SMALL BODY 80009 322325900
A3R373 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R374 322–3273–00 RES,FXD:METAL FILM;6.81K OHM,1%,0.2W,TC=100 91637 CCF50–2–G68100F
A3R379 322–3293–00 RES,FXD:METAL FILM;11K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G11001F
A3R382 322–3381–00 RES,FXD,FILM:90.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2–G9092FT
A3R383 322–3335–00 RES,FXD,FILM:30.1K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30101F
A3R387 322–3281–00 RES,FXD:METAL FILM;8.25K OHM,1%,0.2W,TC=100 91637 CCF501G82500F
A3R388 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R389 315–0106–00 RES,FXD,FILM:10M OHM,5%,0.25W TK1727 SFR25 2322–181–
