Replaceable Electrical Parts
8–34 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A5C211 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C212 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V,, TK1743 CGB103KEX
A5C213 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C220 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C311 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C312 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V TK1743 CGB103KEX
A5C313 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C315 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C411 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C412 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V TK1743 CGB103KEX
A5C413 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A5C500 283–0177–05 CAP,FXD,CER DI:1UF,+80–20%,25V 04222 SR303E105ZAAAP1
A5C510 283–0177–00 CAP,FXD,CER DI:1UF,+80–20%,25V 04222 SR303E105ZAA
A5C515 290–0943–00 CAP,FXD,ALUM:47UF,+50–20%,25V,6 X 11MM 0H1N5 CEUSM1E470–Q
A5C516 290–0943–00 CAP,FXD,ALUM:47UF,+50–20%,25V,6 X 11MM 0H1N5 CEUSM1E470–Q
A5C600 281–0198–00 CAP,VAR,AIR DI:1.7–11PF,250V 74970 187–0306–105
A5J115 174–1168–00 CA ASSY,SP:RIBBON;IDC,10,28AWG,4.25L,2X10,
0.1,PCB,X 2X10,0.1,CTRPLZ,RCPT
TK1386 174–1168–00
A5J200 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J205 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J300 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J305 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J400 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J405 131–3192–00 CONN,RF JACK:BNC;50 OHM,FEMALE,STR,PCB/REAR
PNL,1.375 MLG X 0.125TAIL,W/O FLANGE,W/MTG
POST,METAL BODY,GOLD/NICKEL
00779 227673–1
A5J501 131–4750–00 CONN,HDR:PCB;MALE,STR,1 X 6,0.100 CTR,0.230 MLG X
0.110 TAIL,30 GOLD 53387 2406–6112TB
A5P600 131–4752–00 CONN,HDR::PCB;MALE,45 DEG,1 X 2,0.1CTR,0.240 MLG X
0.110 TAIL,30 GOLD 58050 082–0243–AS10
A5P610 131–4752–00 CONN,HDR::PCB;MALE,45 DEG,1 X 2,0.1CTR,0.240 MLG X
0.110 TAIL,30 GOLD 58050 082–0243–AS10
A5Q200 151–0188–00 TRANSISTOR,SIG:BIPOLAR,PNP;40V,200MA,250MHZ,AMPL 04713 2N3906
A5Q300 151–0216–04 TRANSISTOR,SIG:BIPOLAR,PNP;25V,100MA,170MHZ,AMPL 04713 MPS6523RLRP
A5Q310 151–0190–00 TRANSISTOR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL 04713 2N3904
A5R202 322–3147–00 RES,FXD:METAL FILM;332 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G332R0F
A5R203 322–3148–00 RES,FXD,FILM:340 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2F340R0F
A5R204 322–3085–00 RES,FXD:METAL FILM;75 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G75R00F
A5R206 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A5R208 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A5R209 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A5R210 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A5R211 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A5R212 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A5R213 322–3354–00 RES,FXD:METAL FILM;47.5K OHM,1%,0.2W,TC=100 91637 CCF501G47501F
A5R300 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A5R305 322–3085–00 RES,FXD:METAL FILM;75 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G75R00F
A5R306 322–3139–00 RES,FXD:METAL FILM;274 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G274ROF
A5R309 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A5R310 322–3237–00 RES,FXD,FILM:2.87K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G28700F
