Replaceable Electrical Parts
8–18 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A3Q751 151–0347–02 XSTR,SIG:BIPOLAR,NPN;160V,600MA,100MHZ,AMPL 04713 2N5551RLRP
A3Q753 151–0261–00 XSTR,SIG:BIPOLAR,PNP;60V,50MA,100MHZ,AMPL,DUAL 80009 151026100
A3Q755 151–0347–02 XSTR,SIG:BIPOLAR,NPN;160V,600MA,100MHZ,AMPL 04713 2N5551RLRP
A3Q764 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q771 151–0220–00 TRANSISTOR,SIG:BIPOLAR,PNP;40V,200MA,400MHZ,AMPL 27014 S036228.22
A3Q772 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q773 151–0211–00 TRANSISTOR,SIG:BIPOLAR,NPN;30V VCEO,55V VCBO,
400MA,500MHZ,AMPL
04713 2N3866
A3Q773 342–0324–00 INSULATOR,DISK:TRANSISTOR,NYLON 13103 7717–5N
A3Q790 151–1005–03 TRANSISTOR,SIG:JFET,N–CH;5V,6MA,2MS,500 OHM 66182 SNJ1641
A3Q840 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q842 151–0221–08 TRANSISTOR,SIG:BIPOLAR,PNP;12V,80MA,SWITCHING 27014 PN4258/D75Z
A3Q846 151–0190–00 TRANSISTOR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL 04713 2N3904
A3Q851 151–0916–00 TRANSISTOR,PWR:BIPOLAR,PN;300V,100MA,60MHZ,AMPL 0LUA3 BF472
A3Q857 151–0916–00 TRANSISTOR,PWR:BIPOLAR,PN;300V,100MA,60MHZ,AMPL 0LUA3 BF472
A3Q859 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q860 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q878 151–0190–00 TRANSISTOR,SIG:BIPOLAR,NPN;40V,200MA,300MHZ,AMPL 04713 2N3904
A3Q897 151–0188–00 TRANSISTOR,SIG:BIPOLAR,PNP;40V,200MA,250MHZ,AMPL 04713 2N3906
A3Q898 151–1059–01 TRANSISTOR,SIG:JFET,N–CH;10V,30MA(MIN),30OHM 04713 MPF4391RLRP
A3Q961 151–0220–00 TRANSISTOR,SIG:BIPOLAR,PNP;40V,200MA,400MHZ,AMPL 27014 S036228.22
A3Q971 151–0198–04 TRANSISTOR,SIG:BIPOLAR,NPN;15V,50MA,600 MHZ,AMPL 04713 MPS918RLRP
A3Q972 151–0220–00 TRANSISTOR,SIG:BIPOLAR,PNP;40V,200MA,400MHZ,AMPL 27014 S036228.22
A3Q973 151–0211–00 TRANSISTOR,SIG:BIPOLAR,NPN;30V VCEO,55V VCBO,
400MA,500MHZ,AMPL
04713 2N3866
*ATTACHED PARTS*
342–0324–00 INSULATOR,DISK:TRANSISTOR,NYLON 13103 7717–5N
*END ATTACHED PARTS*
A3Q993 151–0221–08 TRANSISTOR,SIG:BIPOLAR,PNP;12V,80MA,SWITCHING 27014 PN4258/D75Z
A3R109 322–3289–00 RES,FXD:METAL FILM;10K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G10001F
A3R110 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R111 322–3322–00 RES,FXD:METAL FILM;22.1K OHM,1%,0.2W,TC=100 91637 CCF501G22101F
A3R113 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A3R115 322–3354–00 RES,FXD:METAL FILM;47.5K OHM,1%,0.2W,TC=100 91637 CCF501G47501F
A3R117 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R118 322–3261–00 RES,FXD,FILM:5.11K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G5111FT
A3R120 322–3326–00 672–0278–09 672–0278–11 RES,FXD,FILM:24.3K OHM,1%,0.2W,TC–T0MI,SMALL BODY 91637 CCF50–2F24301F
A3R121 322–3294–00 672–0278–12 RES,FXD,FILM:11.3K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G1132FT
A3R142 311–2230–00 RES,VAR,TRMR:CERMET;500 OHM,20%,0.5W,0.197SQ,TOP
ADJUST
TK2073 GF06UT2 501 M L
A3R159 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R167 322–3339–00 RES,FXD:METAL FILM;33.2K OHM,1%,0.2W,TC=100 91637 CCF50–2–G3322FT
A3R168 322–3437–00 RES,FXD,FILM:348K OHM,1%,0.2W,TC=T0MI,SMALL 91637 CCF501G34802F
A3R186 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R187 322–3281–00 RES,FXD:METAL FILM;8.25K OHM,1%,0.2W,TC=100 91637 CCF501G82500F
A3R188 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R189 322–3126–00 RES,FXD,FILM:200 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G200ROF
A3R190 322–3273–00 RES,FXD:METAL FILM;6.81K OHM,1%,0.2W,TC=100 91637 CCF50–2–G68100F
A3R192 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R193 322–3250–00 RES,FXD:METAL FILM;3.92K OHM,1%,0.2W,TC=100 91637 CCF50–2F39200F
A3R194 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R195 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R196 322–3210–00 RES,FXD:METAL FILM;1.5K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G15000F
A3R214 322–3314–00 RES,FXD:METAL FILM;18.2K OHM,1%,0.2W,TC=100 91637 CCF501G18201F
A3R217 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R218 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R219 301–0181–00 RES,FXD,FILM:180 OHM,5%,0.5W TK1727 SFR30 2322–182–
A3R222 307–0023–00 RES,FXD,CMPSN:4.7 OHM,10%,0.5W 50139 EB47G1
