Replaceable Electrical Parts
8–9 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A1R36 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A1R37 322–3034–00 RES,FXD:METAL FILM;22.1 OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G22R10F
A1R38 315–0226–01 RES,FXD,CMPSN:22 M OHM,5%,0.25WALLEN BRADLEY
ONLY
50139 CB2265
A1R39 315–0471–03 RES,FXD,CMPSN:470 OHM,5%,0.25W 50139 CB4715
A1R40 315–0103–03 RES,FXD,CMPSN:10K OHM,5%,0.25W 50139 CB1035
A1R41 322–3121–00 RES,FXD:METAL FILM;178 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G178R0F
A1R42 322–3402–00 RES,FXD:METAL FILM;150K OHM,1%,0.2W,TC=100 PPM 91637 CCF50G15002F
A1R43 315–0471–03 RES,FXD,CMPSN:470 OHM,5%,0.25W 50139 CB4715
A1R44 315–0471–03 RES,FXD,CMPSN:470 OHM,5%,0.25W 50139 CB4715
A1R45 311–2239–00 RES,VAR,TRMR:CERMET;100K OHM,20%,0.5W,0.197 TK2073 GF06UT2 104 M L
A1R46 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R47 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A1R48 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A1R49 311–2239–00 RES,VAR,TRMR:CERMET;100K OHM,20%,0.5W,0.197 TK2073 GF06UT2 104 M L
A1R50 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R51 322–3260–00 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R52 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R53 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R54 322–3260–00 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R55 322–3344–00 671–2890–01 671–2890–01 RES,FXD,FILM:37.4K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G37401F
A1R55 322–3322–00 671–2890–02 RES,FXD:METAL FILM;22.1K OHM,1%,0.2W,TC=100 91637 CCF501G22101F
A1R56 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R57 322–3034–00 RES,FXD:METAL FILM;22.1 OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G22R10F
A1R58 311–2239–00 RES,VAR,TRMR:CERMET;100K OHM,20%,0.5W,0.197 TK2073 GF06UT2 104 M L
A1R59 322–3485–07 RES,FXD,FILM:5K OHM,0.1%,0.2W,TC=T9,SMALL BODY 91637 CCF501C50000B
A1R60 322–3268–00 RES,FXD,FILM:6.04K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G60400F
A1R61 322–3034–00 RES,FXD:METAL FILM;22.1 OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G22R10F
A1R62 322–3097–00 671–2890–07 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A1R63 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A1R64 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A1R65 322–3385–00 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A1R66 322–3452–00 RES,FXD,FILM:499K OHM,1%,0.2W,TC=TOMI,SMALL 91637 CCF50–2–G4993FT
A1R67 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R68 322–3121–00 RES,FXD:METAL FILM;178 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G178R0F
A1R69 322–3289–07 RES,FXD,FILM:10K OHM,0.1%,0.2W,TC=T9,T&R,SM BODY 91637 CCF501C10001B
A1R70 322–3289–07 RES,FXD,FILM:10K OHM,0.1%,0.2W,TC=T9,T&R,SM BODY 91637 CCF501C10001B
A1R71 322–3418–00 RES,FXD:METAL FILM;221K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G22102F
A1R72 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R73 322–3001–00 RES,FXD:METAL FILM;10 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10R00F
A1R74 322–3260–00 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R75 322–3260–00 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R76 322–3260–00 671–2890–01 671–2890–04 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R76 322–3248–00 671–2890–05 RES,FXD,FILM:3.74K OHM,1%,0.2W,TC=T0 91637 CCF50G37400F
A1R77 322–3121–00 671–2890–01 671–2890–06 RES,FXD:METAL FILM;178 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G178R0F
A1R77 322–3097–00 671–2890–07 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A1R78 322–3222–00 671–2890–01 671–2890–06 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A1R78 322–3248–00 671–2890–07 RES,FXD,FILM:3.74K OHM,1%,0.2W,TC=T0 91637 CCF50G37400F
A1R79 322–3356–00 RES,FXD,FILM:49.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G49901F
A1R80 322–3222–00 RES,FXD:METAL FILM;2K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20000F
A1R81 322–3121–00 RES,FXD:METAL FILM;178 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G178R0F
A1R82 322–3260–00 RES,FXD,FILM:4.99K OHM,1%,0.2W,TC=T0 91637 CCF501G49900F
A1R83 322–3289–07 RES,FXD,FILM:10K OHM,0.1%,0.2W,TC=T9,T&R,SM BODY 91637 CCF501C10001B
A1R84 322–3327–00 671–2890–01 671–2890–04 RES,FXD,FILM:24.9K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2–G24901F
A1R84 322–3315–00 671–2890–05 RES,FXD,FILM:18.7K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G18701F
A1R85 322–3452–00 671–2890–01 671–2890–06 RES,FXD,FILM:499K OHM,1%,0.2W,TC=TOMI,SMALL 91637 CCF50–2–G4993FT
A1R85 322–3385–00 671–2890–07 RES,FXD:METAL FILM;100K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10002F
A1R86 308–0793–00 RES,FXD:0.51 OHM,5%,1WTC=150PPM/DEG C,MI 75042 BW20 .51OHM 5PE
