Replaceable Electrical Parts
8–14 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
337–3761–00 SHIELD,ELEC:PLATE,B SWEEP CIRCUIT BOARD TK1947 337–3761–00
*END ATTACHED PARTS*
A3C114 281–0812–00 CAP,FXD,CERAMIC:MLC;1000PF,10%,100V,0.100 X 04222 SA101C102KAA
A3C119 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C156 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A3C187 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C193 281–0799–00 CAP,FXD,CER DI:62PF,2%,100V 04222 SA102A620GAA
A3C197 290–0848–00 CAP,FXD,ALUM:47UF,+100%–20%,16V,NONPOLAR,
0.681X0.414
0H1N5 CEBPM1E470M
A3C215 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C218 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C242 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A3C243 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A3C246 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C255 281–0757–00 CAP,FXD,CERAMIC:MLC;10PF,10%,200V,NPO,0.100 04222 SA102A100KAA
A3C258 281–0759–00 CAP,FXD,CERAMIC:MLC;22PF,10%,100V,0.100 X 0.170 04222 SA102A220KAA
A3C290 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C297 290–0848–00 CAP,FXD,ALUM:47UF,+100%–20%,16V,NONPOLAR,
0.681X0.414
0H1N5 CEBPM1E470M
A3C310 290–0747–00 CAP,FXD,ELCTLT:100UF,+50–20%,25WVDC 0H1N5 CE02W1E101F
A3C336 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C338 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C342 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A3C343 290–0974–03 CAP,FXD,ELCTLT:10UF,20%,60VDC 55680 UVX1H100MAA1TD
A3C348 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C350 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C353 281–0757–00 CAP,FXD,CERAMIC:MLC;10PF,10%,200V,NPO,0.100 04222 SA102A100KAA
A3C354 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V TK1743 CGB103KEX
A3C355 281–0812–00 CAP,FXD,CERAMIC:MLC;1000PF,10%,100V,0.100 X 04222 SA101C102KAA
A3C370 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C379 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C391 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C395 281–0819–00 CAP,FXD,CERAMIC:MLC;33 PF,5%,50V,0.100 X 0.170 04222 SA102A330JAA
A3C399 281–0812–00 CAP,FXD,CERAMIC:MLC;1000PF,10%,100V,0.100 X 04222 SA101C102KAA
A3C424 285–1067–00 CAP,FXD,PLSTC:0.5UF,1%,200V 14752 230B1C504F
A3C436 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C438 281–0767–00 CAP,FXD,CERAMIC:MLC;330PF,20%,100V,0.100 X0.170 04222 SA102C331MAA
A3C446 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C448 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C455 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V TK1743 CGB103KEX
A3C460 281–0182–00 CAP,VAR,PLSTC:1.8–10PF,300V 19701 2805D1R810BH03F
A3C461 281–0756–00 CAP,FXD,CERAMIC:MLC;2.2PF,+/–0.5PF,200V,NPO,0.100 X
0.170
04222 SA102A2R2DAA
A3C462 281–0810–00 CAP,FXD,CERAMIC:MLC;5.6PF,+/–0.5PF,100V,0.100 X 0.170 04222 SA102A5R6DAA
A3C466 281–0767–00 CAP,FXD,CERAMIC:MLC;330PF,20%,100V,0.100 X0.170 04222 SA102C331MAA
A3C469 281–0537–00 CAP,FXD,CERAMIC:MLC;0.68PF,20%,500V,0.170 X TK2058 DA12COG2HR68M
A3C470 281–0537–00 CAP,FXD,CERAMIC:MLC;0.68PF,20%,500V,0.170 X TK2058 DA12COG2HR68M
A3C479 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C482 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C486 281–0763–00 CAP,FXD,CERAMIC:MLC;47PF,10%,100V,0.100 X 0.170 04222 SA102A470KAA
A3C487 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C497 290–0848–00 CAP,FXD,ALUM:47UF,+100%–20%,16V,NONPOLAR,
0.681X0.414
0H1N5 CEBPM1E470M
A3C498 281–0773–00 CAP,FXD,CERAMIC:MLC;0.01UF,10%,100V TK1743 CGB103KEX
A3C516 285–1224–00 CAP,FXD,PLSTC:0.0033UF,1%,200V 84411 TEK 329
A3C521 281–0775–01 CAP,FXD,CERAMIC:MCL;0.1UF,20%,50V,Z5U,0.170 04222 SA105E104MAA
A3C538 281–0767–00 CAP,FXD,CERAMIC:MLC;330PF,20%,100V,0.100 X0.170 04222 SA102C331MAA
A3C547 283–0524–00 CAP,FXD,MICA DI:750PF,5%,500V TK0891 RDM19FD751J03
