Tektronix WFM 300A - Manual (Page 165)

Replaceable Electrical Parts
8–27 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A3CR338 152–0066–00 DIODE,RECT:400V,1A,IFSM=30A,1.2VF,2US 0LUA3 1N5060
A3CR345 152–0066–00 DIODE,RECT:400V,1A,IFSM=30A,1.2VF,2US 0LUA3 1N5060
A3CR347 152–0066–00 DIODE,RECT:400V,1A,IFSM=30A,1.2VF,2US 0LUA3 1N5060
A3CR391 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR414 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR473 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR533 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR590 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR634 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR726 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR727 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR862 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR865 152–0501–01 DIODE,SIG:FAST RCVRY;70V,200MA,100NS,COM–ANODE 04713 MSD6150RLRP
A3CR953 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3CR965 152–0307–00 DIODE,SIG:ULTRA FAST;100V,4.0NS,1.5PF,DUAL 04713 MSD6100
A3CR991 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A3DS505 150–1185–00 672–0278–09 672–0278–09 LT EMITTING DIO:GREEN 95263 L613DG
A3DS505 150–1278–00 672–0278–10 DIODE,OPTO:LED;GRN,569NM,2MCD AT 5V,60 DEGHT AGL 50434 HLMP–1640–010
A3DS700 150–1184–00 672–0278–09 672–0278–09 LT EMITTING DIO:RED 95263 L613DR
A3DS700 150–1201–00 672–0278–10 DIO,OPTO:LED;HIGH EFFIC. RED,635NM,INTEGRAL RES 50434 HLMP–1600–010
A3VR190 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3VR366 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3VR391 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3VR591 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3VR675 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3VR675 152–0195–00 DIODE,ZENER:5.1V,5%,0.4W 14552 CD332125
A3VR840 152–0667–00 DIODE,ZENER:3V,2%,0.4W 04713 SZG30025RL
A3VR948 152–0461–00 DIODE,SIG:6.2V,5%,0.4W 04713 1N821
A3VR992 152–0166–00 DIODE,ZENER:6.2V,5%,0.4W 04713 1N5995BRL
A3A1 671–1365–00 CIRCUIT BD ASSY:TRANSCODER STD
(STANDARD ONLY)
80009 671136500
A3A1 671–1358–00 CIRCUIT BD ASSY:TRANSCODER OPT 10
(OPTION 10 ONLY)
80009 671135800
A3A1P180 ––––––––––– CONN,PLUG,ELEC:
A3A1R782 321–1718–07 671–1358–00 RES,FXD,FILM:1.111K OHM,0.1%,0.125W,TC=T9 19701 5033RE1K111B
A3A1R782 321–0955–03 671–1365–00 RES,FXD,FILM:823 OHM,0.25%,0.125W,TC=T2 MI 07716 CEA 823OHM 0.25
A3A1R783 321–0257–00 671–1358–00 RES,FXD,FILM:4.64K OHM,1%,0.125W,TC=T0MI 19701 5043ED4K640F
A3A1R783 321–1704–03 671–1365–00 RES,FXD,FILM:2.386K OHM,0.25%,0.125W,TC=T2 91637 CMF55116D23860C
A3A1R784 321–1616–02 671–1358–00 RES,FXD,FILM:2.25K OHM,0.5%,0.125W,TC=T2 19701 5033RC2K250D
A3A1R784 321–0199–06 671–1365–00 RES,FXD,FILM:1.15K OHM,0.25%,0.125W,TC=T9 19701 5033RE1K150C
A3A1R785 315–0102–00 671–1358–00 RES,FXD,FILM:1K OHM,5%,0.25W TK1727 SFR25 2322–181–
A3A1R785 315–0821–00 671–1365–00 RES,FXD,FILM:820 OHM,5%,0.25W TK1727 SFR25 2322–181–
A3A1R786 321–0199–06 671–1358–00 RES,FXD,FILM:1.15K OHM,0.25%,0.125W,TC=T9 19701 5033RE1K150C
A3A1R786 322–0173–07 671–1365–00 RES,FXD,FILM:619 OHM,0.1%,0.125W 91637 CCF502C619R0B
A3A1R787 321–0210–07 671–1358–00 RES,FXD:METAL FILM;1.5K OHM,0.1%,0.125W,TC=25 PPM 91637 CMF55116C15000B
A3A1R787 321–1739–07 671–1365–00 RES,FXD,FILM:585.8 OHM,0.1%,0.125W 91637 CMF–55 116C585R
A3A1R788 322–3193–07 671–1358–00 RES,FXD,FILM:1K OHM,0.1%,0.2W,TC=T9 91637 CCF501C10000B
A3A1R788 321–1718–07 671–1365–00 RES,FXD,FILM:1.111K OHM,0.1%,0.125W,TC=T9 19701 5033RE1K111B
A3A1R882 321–0955–03 671–1358–00 RES,FXD,FILM:823 OHM,0.25%,0.125W,TC=T2 MI 07716 CEA 823OHM 0.25
A3A1R882 321–1173–03 671–1365–00 RES,FXD,FILM:626 OHM,0.25%,0.125W,TC=T2 MI 19701 5033RC626R0C
A3A1R884 315–0911–00 671–1358–00 RES,FXD,FILM:910 OHM,5%,0.25W TK1727 SFR25 2322–181–
A3A1R884 315–0182–00 671–1365–00 RES,FXD,FILM:1.8K OHM,5%,0.25W TK1727 SFR25 2322–181–
A3A1R885 322–3193–07 671–1358–00 RES,FXD,FILM:1K OHM,0.1%,0.2W,TC=T9 91637 CCF501C10000B
A3A1R885 321–1718–07 671–1365–00 RES,FXD,FILM:1.111K OHM,0.1%,0.125W,TC=T9 19701 5033RE1K111B
A3A1R886 321–1709–01 671–1358–00 RES,FXD,FILM:800 OHM,0.5%,0.125W,TC=T0MI 19701 5033RD800R0D
A3A1R886 321–1173–03 671–1365–00 RES,FXD,FILM:626 OHM,0.25%,0.125W,TC=T2 MI 19701 5033RC626R0C
A3A1R983 321–0698–00 671–1358–00 RES,FXD,FILM:1.89K OHM,0.25%,0.125W,TC=T9 19701 5033RE1K890C
