Replaceable Electrical Parts
8–11 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A1CR23 152–1165–00 671–2890–06 DIODE,RECT:ULTRA FAST;600V,4A,50NS 04713 MUR460RL
A1CR24 152–0661–00 671–2890–01 671–2890–05 DIODE,RECT:FAST RCVRY;600V,3A,200NS 12954 DR850701B (40SL
A1CR24 152–1165–00 671–2890–06 DIODE,RECT:ULTRA FAST;600V,4A,50NS 04713 MUR460RL
A1CR25 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A1CR26 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A1CR27 152–0400–00 DIODE,RECT:FAST RCVRY;400V,1A,200NS 0LUA3 1N4936
A1CR28 152–0141–02 671–2890–01 671–2890–06 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A1CR29 152–0400–00 DIODE,RECT:FAST RCVRY;400V,1A,200NS 0LUA3 1N4936
A1CR30 152–0141–02 DIODE,SIG:ULTRA FAST;40V,150MA,4NS,2PF 27014 FDH9427
A1CR31 152–0400–00 DIODE,RECT:FAST RCVRY;400V,1A,200NS 0LUA3 1N4936
A1DS1 150–0050–00 LAMP,GLOW:135V MAX,1.9MA,C2A–T,WIRE LEAD 0J9R2 NE–2Q–11R–T
A1DS2 150–0050–00 LAMP,GLOW:135V MAX,1.9MA,C2A–T,WIRE LEAD 0J9R2 NE–2Q–11R–T
A1DS3 150–0050–00 LAMP,GLOW:135V MAX,1.9MA,C2A–T,WIRE LEAD 0J9R2 NE–2Q–11R–T
A1DS4 150–0050–00 LAMP,GLOW:135V MAX,1.9MA,C2A–T,WIRE LEAD 0J9R2 NE–2Q–11R–T
A1TP1 214–4085–00 TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR 26364 104–01–02
A1TP2 214–4085–00 TERM,TEST POINT:0.070 ID,0.220 H,0.063 DIAP
CB,0.015 X 0.032 BRASS,W/RED NYLON COLLAR 26364 104–01–02
A1VR1 156–1631–01 IC,LINEAR:BIPOLAR,VR;ADJUST,SHUNT,100MA,2.2% 01295 TL431CLPM
A1VR2 152–0195–00 DIODE,ZENER:5.1V,5%,0.4W 14552 CD332125
A1VR3 152–0195–00 671–2890–07 DIODE,ZENER:5.1V,5%,0.4W 14552 CD332125
A1VR4 152–0149–00 671–2890–07 DIODE,ZENER:10V,5%,0.4W 04713 1N961BRL
A2 671–1354–00 CIRCUIT BD ASSY:FRONT PANEL 80009 671135400
A2J295 174–0468–00 CA ASSY,SP:RIBBON;IDC,34,28AWG,8.0L,2X17,0.1,RCPT
W/STRAIN RELIEF,X 2X17,0.1,PCB W/OSTRAIN RELIEF
TK0196 ORDER BY DESC
A2R233 311–2321–00 RES,VAR,WW:CLAROSTAT,3 TURN POT 12697 CM45221
A2R233 366–1701–01 KNOB:GY,0.127 ID X 0.392 OD X 0.4 H 80009 366170101
A2R333 311–2321–00 RES,VAR,WW:CLAROSTAT,3 TURN POT 12697 CM45221
*ATTACHED PARTS*
366–1701–01 KNOB:GY,0.127 ID X 0.392 OD X 0.4 H 80009 366170101
*END ATTACHED PARTS*
A2R410 311–2468–00 RES,VAR,NONWW:PNL,20K OHM,20%,0.25W,20MMSHAFT TK2073 RV102YP20S203
*ATTACHED PARTS*
366–1701–01 KNOB:GY,0.127 ID X 0.392 OD X 0.4 H 80009 366170101
*END ATTACHED PARTS*
A2R420 311–2467–00 RES,VAR,NONWW:PNL,20K OHM,20%,0.25W,10MMSHAFT TK2073 RV102YP10S203
A2R430 311–2468–00 RES,VAR,NONWW:PNL,20K OHM,20%,0.25W,20MMSHAFT TK2073 RV102YP20S203
*ATTACHED PARTS*
366–1701–01 KNOB:GY,0.127 ID X 0.392 OD X 0.4 H 80009 366170101
*END ATTACHED PARTS*
A2R445 311–2468–00 RES,VAR,NONWW:PNL,20K OHM,20%,0.25W,20MMSHAFT TK2073 RV102YP20S203
*ATTACHED PARTS*
366–1701–01 KNOB:GY,0.127 ID X 0.392 OD X 0.4 H 80009 366170101
*END ATTACHED PARTS*
A2S109 260–2300–00 SWITCH,SIG:SPST;PUSH,MOM,NO,W/GROUND TERM,
MANUAL INSERTION,100 GRAMS,SILVER,SEALED
34361 B3F1152
*ATTACHED PARTS*
366–0616–00 PUSH BUTTON:0.585 X 0.3 X 0.150 7X318 ORDER BY DESC
*END ATTACHED PARTS*
A2S125 260–2300–00 SWITCH,SIG:SPST;PUSH,MOM,NO,W/GROUND TERM,
MANUAL INSERTION,100 GRAMS,SILVER,SEALED
34361 B3F1152
*ATTACHED PARTS*
366–0616–00 PUSH BUTTON:0.585 X 0.3 X 0.150 7X318 ORDER BY DESC
*END ATTACHED PARTS*
A2S142 260–2300–00 SWITCH,SIG:SPST;PUSH,MOM,NO,W/GROUND TERM,
MANUAL INSERTION,100 GRAMS,SILVER,SEALED
34361 B3F1152
*ATTACHED PARTS*
366–0616–00 PUSH BUTTON:0.585 X 0.3 X 0.150 7X318 ORDER BY DESC
