Replaceable Electrical Parts
8–21 WFM 300A
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description
Serial / Assembly Number
Effective Discontinued Tektronix
Part Number
A3R485 322–3189–00 RES,FXD,FILM:909 OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G909FOR
A3R487 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R488 322–3281–00 RES,FXD:METAL FILM;8.25K OHM,1%,0.2W,TC=100 91637 CCF501G82500F
A3R489 322–3239–00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G30100F
A3R490 311–2232–00 RES,VAR,TRMR:CERMET;2K OHM,20%,0.5W,0.197 SQ,TOP
ADJUST
TK2073 GF06UT2 202 M L
A3R491 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R492 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R493 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R495 322–3457–00 RES,FXD,FILM:562K OHM,1%,0.2W,TC=T0MI,SMALL 91637 CCF50–2F56202F
A3R496 311–2238–00 RES,VAR,TRMR:CERMET;50K OHM,20%,0.5W,0.197
SQ,SIDE ADJUST
TK2073 GF06UT2 503 M L
A3R497 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R498 315–0305–00 RES,FXD,FILM:3M OHM,5%,0.25W TK1727 SFR25 2322–181–
A3R500 311–2269–00 RES,VAR,NONWW:TRMR,20K OHM,20%,0.5WLINEAR,MI TK2073 GF06VT2 203 M L
A3R506 322–3130–00 RES,FXD:METAL FILM;221 OHM,1%,0.2W,TC=100 PPM 57668 RB20FX221E
A3R507 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R508 322–3268–00 RES,FXD,FILM:6.04K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G60400F
A3R513 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R514 322–3227–00 RES,FXD,FILM:2.26K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF502G2261FT
A3R515 322–3240–00 RES,FXD,FILM:3.09K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–2G30900F
A3R516 315–0155–00 RES,FXD,FILM:1.5M OHM,5%,0.25W TK1727 SFR25 2322–181–
A3R517 322–3443–00 RES,FXD,FILM:402K OHM,1%,0.2W,TC=T0MI,SMALL 91637 CCF501G40202F
A3R518 322–3294–00 RES,FXD,FILM:11.3K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G1132FT
A3R519 322–3377–00 RES,FXD:METAL FILM;82.5K OHM,1%,0.2W,TC=100 91637 CCF50–2F82501F
A3R520 322–3377–00 RES,FXD:METAL FILM;82.5K OHM,1%,0.2W,TC=100 91637 CCF50–2F82501F
A3R521 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R522 322–3202–00 RES,FXD,FILM:1.24K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–1G12400F
A3R523 322–3231–00 RES,FXD,FILM:2.49K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–1G24900F
A3R524 322–3202–00 RES,FXD,FILM:1.24K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50–1G12400F
A3R525 322–3218–00 RES,FXD:METAL FILM;1.82K OHM,1%,0.2W,TC=100 91637 CCF501G18200F
A3R526 322–3200–00 RES,FXD,FILM:1.18K OHM,1%,0.2W,TC=T0MI,SMALL BODY 57668 CRB20 FXE 1K18
A3R527 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R528 322–3265–00 RES,FXD:METAL FILM;5.62K OHM,1%,0.2W,TC=100 91637 CCF501G56200F
A3R529 322–3306–00 RES,FXD:METAL FILM;15K OHM,1%,0.2W,TC=100 PPM 91637 CCF50–2–G1502F
A3R532 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R533 322–3200–00 RES,FXD,FILM:1.18K OHM,1%,0.2W,TC=T0MI,SMALL BODY 57668 CRB20 FXE 1K18
A3R534 311–2232–00 RES,VAR,TRMR:CERMET;2K OHM,20%,0.5W,0.197 SQ,TOP
ADJUST
TK2073 GF06UT2 202 M L
A3R535 322–3297–00 RES,FXD:METAL FILM;12.1K OHM,1%,0.2W,TC=100 91637 CCF501G12101F
A3R540 322–3237–00 RES,FXD,FILM:2.87K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G28700F
A3R541 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R544 322–3285–00 RES,FXD,FILM:9.09K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF501G90900F
A3R547 322–3258–00 RES,FXD:METAL FILM;4.75K OHM,1%,0.2W,TC=100 56845 CCF50–2–G4751FT
A3R548 315–0226–00 RES,FXD,FILM:22M OHM,5%,0.25W 50139 CB2265
A3R549 322–3097–00 RES,FXD:METAL FILM;100 OHM,1%,0.2W,TC=100 PPM 91637 CCF501G100R0F
A3R551 311–2237–00 RES,VAR,TRMR:CERMET;25K OHM,20%,0.5W,0.197
SQ,SIDE ADJUST
TK2073 GF06UT2 253 M L
A3R552 322–3339–00 RES,FXD:METAL FILM;33.2K OHM,1%,0.2W,TC=100 91637 CCF50–2–G3322FT
A3R553 322–3414–00 RES,FXD:METAL FILM;200K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G20002F
A3R554 322–3210–00 RES,FXD:METAL FILM;1.5K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G15000F
A3R555 322–3181–00 RES,FXD,FILM:750 OHM,1%,0.2W,TC=T0MI,SMALL
BODY
91637 CCF501G750ROF
A3R556 322–3261–00 RES,FXD,FILM:5.11K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G5111FT
A3R557 322–3261–00 RES,FXD,FILM:5.11K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G5111FT
A3R558 322–3210–00 RES,FXD:METAL FILM;1.5K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G15000F
A3R560 322–3193–00 RES,FXD:METAL FILM;1K OHM,1%,0.2W,TC=100 PPM 91637 CCF501G10000F
A3R561 322–3261–00 RES,FXD,FILM:5.11K OHM,1%,0.2W,TC=T0MI,SMALL BODY 91637 CCF50G5111FT
