English 9
Model and Parts Identification
— 30” Range
Key for 30" Model
1.
6" Low Back (Island Trim and Pot-and-Pan Shelf
ordered separately)
2.
Burner Grates & Burners
3.
Center Grate
4.
Control Knobs, ExtraLow
®
Burners (2)
5.
Control Knobs, Standard Burners (2)
6.
Oven Temperature Selector
7.
Oven Mode Selector
8.
Oven Door
9.
Viewing Window
10. Kick Panel
11. Range Feet (4)
WARNING:
To provide proper ventilation, do NOT remove
range feet.
Electric Oven Interior
Please see Figure 3.
Figure 5: 30" Model
1
4
2
2
3
5
6
7
8
9
11
11
10
