Program mode menu navigation, Torque – Toshiba H9 User Manual
Page 67
H9 ASD Installation and Operation Manual
59
M
OTOR
PM Motor
Step-Out Detection-current Level (for PM motors)
Step-Out Detection-current Time (for PM motors)
Vector Motor Model
Autotune 1
Slip Frequency Gain
Autotune 2
Motor Rated Capacity (nameplate)
Motor Rated Current (nameplate)
Motor Rated RPM (nameplate)
Base frequency Voltage 1
Motor Constant 1 (torque boost)
Motor Constant 2 (no load current)
Motor Constant 3 (leak inductance)
Motor Constant 4 (rated slip)
T
ORQUE
Torque
Manual Torque Limit
Settings
Power Running Torque Limit 2 Level
Regenerative Braking Torque Limit 2 Level
Power Running Torque Limit 3 Level
Regenerative Braking Torque Limit 3 Level
Power Running Torque Limit 4 Level
Regenerative Braking Torque Limit 4 Level
Setpoints
V/I Input Point 1 Rate
V/I Input Point 2 Rate
RR Input Point 1 Rate
RR Input Point 2 Rate
RX Input Point 1 Rate
RX Input Point 2 Rate
RX2 Option (AI1) Input Point 1 Rate
RX2 Option (AI1) Input Point 2 Rate
Torque Control
Braking Mode
Torque Bias Input
Panel Torque Bias
Panel Torque Gain
Program Mode Menu Navigation
Primary Menu
Sub Menu
Parameter Name
Parameter
Number
