H9 ASD Installation and Operation Manual 245
Table 11. My Function Operator selections.
My Function Computational Selections
Input
Function
Command
Function Name Function Description
0 NOP (No Operation) Disables the My Function feature.
1 ST Execute data read/transfer.
2 STN Execute inverted data read/transfer.
3 AND Logical product of A AND B.
4 ANDN Logical product of A AND B.
5 OR Logical sum of A OR B.
6 ORN Logical sum of A OR B.
7 EQ Compares data — Outputs 1 if Equal; 0 if not Equal.
8 NE Compares data — Outputs 0 if Equal; 1 if not Equal.
9 GT Compares data — Outputs 1 if A>B; 0 if A ≤B.
10 GE Compares data — Outputs 1 if A
≥B; 0 if A
11 LT Compares data — Outputs 1 if A
12 LE Compares data — Outputs 1 if A
≤B; 0 if A>B.
13 ASUB Outputs absolute difference between A and B — |A–B|
14 ON (Timer)
Enables the On response time delay settings of My Function Time Data 1 – 5
(
F928 – F932 ) for My Function Data.
15 OFF (Timer)
Enables the Off response time delay settings of My Function Time Data 1 – 5
(
F928 – F932 ) for My Function Data.
16 COUNT1 (Timer) Outputs a 1 upon reaching the pulse count setting of F933 .
17 COUNT2 (Timer) Outputs a 1 upon reaching the pulse count setting of F934 .
18 HOLD Outputs the peak output value since powering up or since the last reset.
19 SET Sets data.
20 RESET Resets data.
