H9 ASD Installation and Operation Manual
103
V/f Five-Point Setting Voltage 2
Program
⇒
Special
⇒
V/f Five-Point Setting
The V/f Five-Point Setting Voltage 2 establishes the output voltage level that
is to be associated with the frequency setting of
(V/f Five-Point Setting
Frequency 2).
The
parameter setting will determine if the selection for this parameter
appears in the form of a Voltage (V) or as a Percentage (%) of the ASD rating.
The default setting is %.
See
and
for additional information on this setting.
Direct Access Number — F193
Parameter Type — Numerical
Factory Default — 0.0
Changeable During Run — No
Minimum — 0.0
Maximum — 100.0
Units — V or % (
V/f Five-Point Setting Frequency 3
Program
⇒
Special
⇒
V/f Five-Point Setting
The Custom V/f Five-Point Setting Frequency 3 sets the frequency to be
associated with the voltage setting of parameter
(V/f Five-Point Setting
Voltage 3).
See
and
for additional information on this setting.
Direct Access Number — F194
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — No
Minimum — 0.00
Maximum — Max. Freq. (
Units — Hz
V/f Five-Point Setting Voltage 3
Program
⇒
Special
⇒
V/f Five-Point Setting
The V/f Five-Point Setting Voltage 3 establishes the output voltage level that
is to be associated with the frequency setting of
(V/f Five-Point Setting
Frequency 3).
The
parameter setting will determine if the selection for this parameter
appears in the form of a Voltage (V) or as a Percentage (%) of the ASD rating.
The default setting is %.
See
and
for additional information on this setting.
Direct Access Number — F195
Parameter Type — Numerical
Factory Default — 0.0
Changeable During Run — No
Minimum — 0.0
Maximum — 100.0
Units — V or % (
V/f Five-Point Setting Frequency 4
Program
⇒
Special
⇒
V/f Five-Point Setting
The Custom V/f Five-Point Setting Frequency 4 sets the frequency to be
associated with the voltage setting of parameter
(V/f Five-Point Setting
Voltage 4).
See
and
for additional information on this setting.
Direct Access Number — F196
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — No
Minimum — 0.00
Maximum — Max. Freq. (
Units — Hz
V/f Five-Point Setting Voltage 4
Program
⇒
Special
⇒
V/f Five-Point Setting
The V/f Five-Point Setting Voltage 4 establishes the output voltage level that
is to be associated with the frequency setting of
(V/f Five-Point Setting
Frequency 4).
The
parameter setting will determine if the selection for this parameter
appears in the form of a Voltage (V) or as a Percentage (%) of the ASD rating.
The default setting is %.
See
and
for additional information on this setting.
Direct Access Number — F197
Parameter Type — Numerical
Factory Default — 0.0
Changeable During Run — No
Minimum — 0.0
Maximum — 100.0
Units — V or % (
