264

H9 ASD Installation and Operation Manual

Table 19. 460 Volt UL Type-1/IP-20 Chassis standard ratings table.

Model

Number

VT130H9U

100% Output

Current

Continuous

Overload Current

120% for 60

Seconds

Input Voltage

3-Ph 50/60

± 2 Hz

Output Voltage

3-Ph Variable

Frequency

Typical

Motor HP

4055

7.6 A

9.0 A

380 – 480 VAC

(±10%)

Input Voltage

Level (Max.)

5.0

4080

11 A

13 A

7.5

4110

14 A

17 A

10

4160

21 A

25 A

15

4220

27 A

32 A

20

4270

34 A

41 A

25

4330

40 A

48 A

30

4400

52 A

62 A

40

4500

65 A

78 A

50

4600

77 A

92 A

60

4750

96 A

115 A

75

410K

124 A

149 A

100

412K

156 A

187 A

125

415K

180 A

216 A

150

420K

240 A

288 A

200

425K

302 A

362 A

250

430K

361 A

433 A

300

435K

414 A

497 A

350

440K

477 A

572 A

400
