– 42 –

No. 1 2 3 4 5 6 7 8

No. 1 2 3 4

9 10

DIP-SW 1

DIP-SW 2

10-3. USB Interface Model

ON

ON

OFF

OFF

DIP-SW

1

Switch 1-1

Switch 1-2

Command emulation

ON

ON

Star Line Mode

OFF

ON

Star Page Mode

ON

OFF

-

OFF

OFF

ESC/POS Mode

The factory settings of DIP switch are all on.

The functions of switches 1-3 through 1-10 will change according to the command emulation

that has been set using switch 1-1 and 1-2.

(1) Star Line Mode

Switch

Function

ON

OFF

1-1

Command emulation

Always ON

1-2

Command emulation

Always ON

1-3

Should not be changed (Should be set to on)

1-4

Sensor adjustment

Invalid

Valid

1-5

USB mode

Printer class

Vendor class

1-6

Handshaking conditions

(conditions for BUSY)

Offline or receive

buffer full

Receive buffer full

1-7

ASB function *1

Printer class

Valid

Invalid

Vendor class

Invalid

Valid

1-8

NSB function *2

Printer class

Valid

Invalid

Vendor class

Invalid

Valid

1-9 ~1-10

Should not be changed (Should be set to on)

*1 ASB Function

When this function is enabled, status information is automatically sent to the host whenever the

printer status changes (such as when the cover is opened, paper runs out, or an error occurs).

For information about automatic status information transmission, refer to the separate Program-

mer's Technical Reference manual (Star Line Mode, Star Page Mode, and ESC/POS Mode).
*2 NSB Function

When this function is enabled, status information is sent automatically whenever the printer

enters into reverse forwarding mode.

For information about automatic status information transmission, refer to the separate Program-

mer's Technical Reference manual (Star Line Mode and Star Page Mode).
