Detailed diagram of effective printing range – Oki RT322POS User Manual
Page 24

– 20 –
ø100 MAX
110
+1.5
-1.0
(Rolled dimension)
ш32 ± 1
ш25.4 ± 1
1
+1.0 -0.8
15 MIN
(2.5)
105 ± 0.5
(Label width)
110 ± 0.5
(Backing paper width)
2.5 ± 0.5
5 ± 1.0
35 – 300
(Black mark pitch)
30 ±1 – 295 ±3
(Label length)
• Detailed Diagrams of Recommended Tack Label Specifications
Tack label
Paper tube
Release paper
(backing paper)
Base material
(label paper)
Printing direction
Black mark (back
of diagram)
PCS: 0.90 minimum
5 ± 1
• Detailed Diagram of Effective Printing Range
3 (Bottom margin)
(2.5)
2.5 ± 0.5
3 (T
op margin)
5 (Left margin)
3 (Right margin)
24 – 289 (Ef
fective printing length)
30 – 295 (Label length)
35 – 300 (Black mark pitch)
105 ± 0.5 (Label width)
110 ± 0.5 (Backing paper width)
95 (effective printing width:
63 characters with font A)
Dot numbers 39 – 598
*
Minimum settable top margin when
paper is fed using back-feed.
Effective printing range
