Oki RT322POS User Manual
Page 17

– 13 –
3-7-1. Removing the Tension Bar
When using thermal paper roll, the tension bar unit may or may not be necessary, depending
on the paper thickness. If the tension bar unit is unnecessary, remove it in accordance with the
procedure indicated below. The tension bar unit is unnecessary when using thermal label paper
roll (tack label paper).
Paper thickness
between 100 μm and 150 μm
Necessary
Paper thickness
between 65 μm and 100 μm
Unnecessary
Use a flat head screwdriver as shown to remove the clips
at both ends of the tension bar. Then, remove the tension
bar unit.
Needed Optional
Vertical Kit
Needed Optional
Wall-mount Kit
Horizontal
