Parts identification: top feed (single-sheet), User’s guide: english 17, Micro feed up micro feed down – Oki 391 User Manual
Page 17
|
User’s Guide: English
17
QUIET
PARK
TEAR
FF/LOAD
LF
SEL
SEL
POWER
ALARM
MENU
GROUP
EXIT
ITEM
SET
MENU
SHIFT
TOF
Micro Feed
Up
Micro Feed
Down
PRINT QUALITY
CHARACTER PITCH
HSD
NLQ
UTL
SSD
10
12
15
17
20
PROP
Parts Identification: Top Feed
(Single-Sheet)
1 Paper Guides
2 Paper Separator
3 Paper Lever
4 On-Off Switch
5 Platen Knob
6 Control Panel
7 Acoustic Cover (open)
8 Access Cover
!
Move the paper lever to the position marked “TOP.”
The paper lever is towards the back of the printer.
32T-15.eps
8
7
5
4
2
6
3
1
