DESCRIPTION OF CONTROLS
(P. 27)
(P. 9)
Rewind Shaft
Film Chamber
Film Guide
Pins (2)
Shutter Curtain
Motor
Guide Pin Hole
Battery
Chamber
Motor Drive Socket Cap
Tripod Socket
Camera Back
Camera Back
Pressure Plate
(P. 37)
Motor Coupling Terminal
Refer to pages in parentheses for detailed explanations of each part.
Film Take-Up
Spool
Viewfinder
Eyepiece Frame
Battery
Check Lamp
Recordata Back Contact
Dual Sprocket
B LOCK Button
(P. 12)
(P. 9, P 44)
(P.58)
( P . 8 )
(P. 43)
(P. 37, P. 40)
(P. 7)
(P.37, P40)
Release Pin
