AMC-101 Installation & Operation Manual
Chapter 2 - Installation & Setup
AMC-101 Modules
2-21
SF1/ST/R Module
Figure 2-22 SF1/ST/R Module Front Panel
Wavelength:
Transmit: 1300 nm; Receive: 1550 nm
Connector:
ST
Used with:
Single mode fiber
Protocols supported:
STS-3c, STM-1, STS-1, FDDI, TAXI
and Fast Ethernet
Timing mode:
Retimed
Optical output into 9/125 fiber:
-12 dBm
Receiver sensitivity:
-29 dBm
