Main Specifications
RP201: Digital Piano
Keyboard 88 keys PHA α II (Progressive Hammer Action α II )
Touch Sensitivity Touch: 5 levels/Fixed Touch
Keyboard Mode Whole
Dual (volume balance adjustable)
Split (split point adjustable)
Twin Piano
88-key Stereo Multi-sampled Piano Sound, Conforms to GM2/GS/XGlite
Max. Polyphony 128 voices
Tones 306 tones (including 8 drum sets, SFX set)
Temperament 8 types, selectable Temperament Key
Stretch Tuning On/Off
Master Tuning 415.3–466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose Transpose: -6–+5 (in semitones)
Playback Transpose: -6–+5 (in semitones)
Effects Reverb (Off/1–10),
String Resonance (only for piano tones, Off/1–10)
Damper Resonance (only for piano tones, Off/1–10)
Key Off Resonance (only for piano tones, Off/1–10),
Tracks 1 track
Songs Recorder Section: 1 song
Internal Memory: Max. 20 songs
Note Storage Approx. 30,000 notes
Control Song Select, Play/Stop, Rec, Previous/Rewinding, Next/Fast-forwarding, Track Mute, Tempo, Tempo Mute,
All Song Play, Count-in, Song Volume
Tempo Quarter note = 10 to 500
Resolution 120 ticks per quarter note
Metronome Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8
Volume: 0–10
Songs Max. 20 songs
Save Song Standard MIDI Files (Format 0)
Internal Songs 65 songs
Rated Power Output 12 W x 2
Speakers 12 cm x 2
Display 7 segments, 3 characters LED
Control Volume
Pedal Damper (capable of continuous detection)
Soft (capable of continuous detection, function assignable),
Sostenuto (function assignable)
Other Function Panel Lock, V-LINK
Connectors DC In jack
Pedal connector
Input jacks (L/Mono, R)
Output jacks (L/Mono, R)
MIDI connector (In, Out)
Phones jack (Stereo) x 2
