Basics

4.5 Electrical Interference

To minimize electrical or electromagnetic interference or “noise” be
aware of the following:

• Mount the unit as far away as possible from potential sources

of electrical interference such as motorized equipment
producing large step load changes.

• Use shielded wire for all input and output connections.
• Make sure the shield wires are earth grounded at one point.
• Sensor head shield braid should make direct contact around

the cable circumference.

MID
