Connecting Your Amp or Speakers
( OUTPUT/ PHONES)
The VP-770 doesn’t contain an amp or speakers. In order to hear sound, you’ll need to connect it to monitor
speakers (with a built-in amp), a stereo set or other audio system, or headphones.
To prevent malfunction and/or damage to speakers or other devices, always turn down the volume,
and turn off the power on all devices before making any connections.
Make connections as shown.
If you’re outputting in mono, connect your equipment to the L/MONO jack.
Audio cables and headphones aren’t included with the VP-770. You’ll need to obtain them sepa-
rately.
*
1.
✍
✍
Monitor speaker (with built-in amp)
Headphones
INPUT
