JA6

Pin Generic Header Name

CPU board

Signal Name

Device

Pin

Pin

Generic Header Name

CPU board

Signal Name

Device

Pin

1 DREQ

NC

-

2 DACK

NC

-

3 TEND

NC

-

4 STBYn

NC

-

5 RS232TX

RS232TX

-

6 RS232RX

RS232RX

-

7 SCIbRX

NC

-

8

SCIbTX NC

-

9 SCIcTX

TXD2

58

10 SCIbCK

NC

-

11 SCIcCK

SCK2

61

12 SCIcRX

RXD2

60

13 -

-

-

14 -

-

-

15 -

-

-

16 -

-

-

17 -

-

-

18 -

-

-

19 -

-

-

20 -

-

-

21 -

-

-

22 -

-

-

23 -

-

-

24 -

-

-

Table 9-8: JA6 Standard Generic Header
