Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R118 Application
board interface
Use A1 of application board
interface.
Use TXD0 for onboard RS232
module.
R120
R124 Application
board interface
Use RXD0 for onboard RS232
module.
Use A0 of application board
interface.
R121
R121 Application
board interface
Use A0 of application board
interface.
Use RXD0 for onboard RS232
module.
R124
Table 6-7: Application board interface links.
Table 6-8 below describes the function of the option links associated with E8A and E10A debuggers. The default configuration is indicated
by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R178 E8A If FWE or R178 is fitted the Flash is
protected from writing.
If both FWE and R178 are
removed, writing to Flash is
enabled.
Table 6-8: E8A and E10A debugger links.
Table 6-9 below describes the function of the option links associated with power source. The default configuration is indicated by BOLD
text.
