Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R67 Application
board interface
Use A17 of application board
interface.
Use SDA of application board
interface “or” IRQ1 for onboard
SW2.
R66, R68
R81 Application
board interface
Use SCL of application board
interface.
Use IRQ0 for onboard SW1 “or”
A16 of application board
interface.
R82, R83
R83 Application
board interface
Use IRQ0 for onboard SW1. Use SCL”or” A16 of application
board interface.
R81, R82
R82 Application
board interface
Use A16 of application board
interface.
Use SCL of application board
interface “or” IRQ0 for onboard
SW1.
R81, R83
R70 Application
board interface
Use UD of application board
interface.
Use CAN_EN for onboard RCAN
module.
R69
R69 Application
board interface
Use CAN_EN for onboard RCAN
module.
Use UD of application board
interface.
R70
R74 Application
board interface
Use IO6 of application board
interface.
Use A10 of application board
interface.
R73
R73 Application
board interface
Use A10 of application board
interface.
Use IO6 of application board
interface.
R74
R88 Application
board interface
Use IO5 of application board
interface.
Use A9 of application board
interface.
R90
R90 Application
board interface
Use A9 of application board
interface.
Use IO5 of application board
interface.
R88
R84 Application
board interface
Use IO4 of application board
interface.
Use A8 of application board
interface.
R85
R85 Application
board interface
Use A8 of application board
interface.
Use IO4 of application board
interface.
R84
R92 Application
board interface
Use ADTRGn of application board
interface.
Use A7 ”or” IO3 of application
board interface.
R94, R96
R94 Application
board interface
Use A7 of application board
interface.
Use ADTRGn “or” IO3 of
application board interface.
R92, R96
R96 Application
board interface
Use IO3 of application board
interface.
Use ADTRGn “or” A7 of
application board interface.
R92, R94
R91 Application
board interface
Use A6 of application board
interface.
Use IO2 of application board
interface.
R89
R89 Application
board interface
Use IO2 of application board
interface.
Use A6 of application board
interface.
R91
