LCD

Pin

Circuit Net Name

Device

Pin

Pin

Circuit Net Name

Device

Pin

1 Ground

-

2 5V

Only

-

3 No

Connection

-

4

DLCDRS (PD10)

28

5

R/W (Wired to Write only)

-

6

DLCDE + 100k pull down to ground (PD9)

29

7 No

Connection

-

8 No

connection

-

9 No

Connection

-

10 No

connection

-

11

DLCDD4 (PE0)

27

12

DLCDD5 (PE1)

26

13

DLCDD6 (PE2)

25

14

DLCDD7 (PE3)

24

Table 6-5 Debug LCD Module Connections
