Renesas SH2/7137 User Manual
Page 28
J4
Pin
Circuit Net Name
Device
Pin
Pin
Circuit Net Name
Device
Pin
1 AN14
81
2 AN13
82
3 AN12
83
4 PIN84
84
5 PIN85
85
6 PIN86
86
7 ADPOT
87
8 CON_AVREF
88
9 AN7
89
10 AN6
90
11 AN5
91
12 AN4
92
13 CON_AVSS
93
14 AN3
94
15 AN2
95
16 AN1
96
17 AN0
97
18 CON_AVCC
98
19 UC_VCC
99
20 WDT_OVFn
100
Table 9-4: J4
