Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R93 Application
board interface
Use TXD2 for onboard RS232
module.
Use IO1 of application board
interface.
R95
R95 Application
board interface
Use IO1 of application board
interface.
Use TXD2 for onboard RS232
module.
R93
R112 Application
board interface
Use RXD2 for onboard RS232
module.
Use WRLn, WRn “or” IO0 of
application board interface.
R101, R105,
R109
R105 Application
board interface
Use WRLn of application board
interface.
Use RXD2 for onboard RS232
module “or” WRn “or” IO0 of
application board interface.
R101, R109,
R112
R109 Application
board interface
Use WRn of application board
interface.
Use RXD2 for onboard RS232
module “or” WRLn “or” IO0 of
application board interface.
R101, R105,
R112
R101 Application
board interface
Use IO0 of application board
interface.
Use RXD2 for onboard RS232
module “or” WRLn “or” WRn of
application board interface.
R105, R109,
R112
R108 Application
board interface
Use IRQ3 of application board
interface.
Use of CAN_ERRn for onboard
RCAN module “or” A5 application
board interface.
R104, R111
R111 Application
board interface
Use CAN_ERRn for onboard RCAN
module.
Use IRQ3 “or” A5 of application
board interface.
R104, R108
R104 Application
board interface
Use A5 of application board
interface.
Use CAN_ERRn for onboard
RCAN module “or” IRQ3 of
application board interface.
R108, R111
R115 Application
board interface
Use PTTX of E8A debugger
interface.
Use A4 of application board
interface.
R113
R113 Application
board interface
Use A4 of application board
interface.
Use PTTX of E8A debugger
interface.
R115
R114 Application
board interface
Use PTRX of E8A debugger
interface.
Use A3 of application board
interface.
R116
R116 Application
board interface
Use A3 of application board
interface.
Use PTRX of application board
interface.
R114
R117 Application
board interface
Use SCK0 of application board
interface.
Use A2 of application board
interface.
R119
R119 Application
board interface
Use A2 of application board
interface.
Use SCK0 of application board
interface.
R117
R120 Application
board interface
Use TXD0 for onboard RS232
module.
Use A1 of application board
interface.
R118
