51
Table 2.12 Measurement Items (cont)
Classification Type Measurement Item Option Note
System bus
performance
(only available
for Ch3 and
Ch4) System bus Number of requests RQ The number of valid bus cycles
(cells) is counted by the
system bus clock.
Number of
responses
RS The number of valid bus cycles
(cells) is counted by the
system bus clock.
Waited cycles for
request WRQ The cycles for an issued
request (req), that no
acceptance signal (gnt) is
issued to, are counted by the
system bus clock.
Even if the waits are issued
simultaneously for multiple
requests, they are counted as
1.
Waited cycles for
response WRS The cycles for an issued
response (r_req), that no
acceptance signal (r_gnt) is
issued to, are counted by the
system bus clock.
Even if the waits are issued
simultaneously for multiple
requests, they are counted as
1.
