Renesas Emulator System SH7362 User Manual
Page 22
14
Notes: 1. Do not use /RESETP in the emulator after the user system has been activated.
When reset signals are used for debugging, use /RESETA.
2. Fix /RESETA as high level when it is not used.
3. When the voltage level of VccQ_SR (power supply for H-UDI and AUD) is 2.85 V
and that of VccQ_MFI (power supply for /RESETA) is 1.8 V, a level-shift circuit is
required as shown in the figure.
