78
Repair Parts
PARTS LIST FOR RIDGID 10" RADIAL SAW
MODEL NUMBER RS10000
Figure 5 - Arm Assembly
Always order by Part Number - Not by Key Number
* Standard Hardware Item - May Be Purchased Locally
1
2
3
4
5
6
7
8
9
j
10
11
12
13 14
15
16
17
18
19
20
2
5 5
11
10 j
21
22
23
24
25
26
27
19
21
22
j If this part is removed,
discard and replace
with a new push nut.
28
29
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
63626
63629
63631
63628
9420417
63883
63632
63630
805814
802612-8
60332
827881
805552-7
802612-6
63638
63637
Housing, Pin
Pin, Arm Lock
Pawl, Arm Lock
Spring, Tension
* Screw, Type “T” Hex
Washer Hd 1/4-20 x 5/8
Guide
Rod, Index
Spring, Arm Lock
Rod, Arm Lock
* Nut, Push 3/8
* Washer, 21/64 x 1 x 1/8
Lever, Arm Lock
* Washer, 17/64 x 5/8 x 1/32
* Nut, Push 1/4
Pin, Lever
Pin
Key
No.
Part No. Description
17
18
19
20
21
22
23
24
25
26
27
28
29
63636
63773
13848
114603
805840
448337
826122
60337
826123
827882
827637
810659
827883
Pin, Clevis
Insulation
* Screw, Type 'T' Pan Hd
10-32 x 1/2
* Lockwasher, Ext. Tooth N10
Track
Screw, Type 'T' Rd. Hd
10-32 x 5/8
Key Switch
* Screw, Type 'T' Pan Hd
10-32 x 7/8
Switch, Locking
(Includes Key No. 23)
Cap, Arm
Arm, Radial
Clamp, Cord
Retainer Switch
