Operation
CinemaWall Installation/Operation Manual 43
PRE
L
IMINAR
Y
MULTI PIP SETUP: The CinemaWall can display an image from two sources at the same
time in a variety of ways. To set up this feature, select MULTI PIP SETUP from the SET UP
menu and press the ACTION (
) button.
• MULTI PIP: Select one of the following to define the behavior of the MULTI PIP
function. To switch to a different multi-PIP display mode, press the MULTI PIP remote
control button repeatedly.
• PIP: With PIP, three multi-PIP display modes are available:
• ADVANCED PIP: Advanced PIP provides eight different multi-PIP display modes:
• BLEND PIP: Use Blend PIP to create a composite image from two sources. For
example, you can use a computer to display a caption over a movie or still image, in
either full-screen or picture-in-picture display mode:
• DISPLAY MODE: Select DISPLAY MODE from the MULTI PIP SETUP menu to
choose one of the multi-PIP display modes shown above. (This control has the same
effect as pressing the MULTI PIP remote control button repeatedly.)
Be aware that if you install the CinemaWall in a public place for
commercial purposes or a public showing, using Blend PIP to
create a composite image may violate copyright laws. It is
prohibited to show or alter copyrighted materials for commercial
purposes without the copyright owner’s permission.
A B A
B
A A
B
[Picture out Picture]
Main picture Sub picture
[Picture and Picture] [Picture in Picture]
Main picture Sub picture Main picture Sub picture
[NORMAL]
Sub screen Main screen
[NORMAL] [1] [2] [3] [4]
[8] [7] [6] [5]
A B C D
B C D
[FULL] [NORMAL] [Picture in Picture]
Note
