Page 21: Pre l iminar y
CinemaWall Installation/Operation Manual
7
PRE
L
IMINAR
Y
Connectors
Figure 2-3 shows the rear-panel connector locations on the CinemaWall.
Figure 2-3. CinemaWall Rear Panel
1.
SLOT 1 (Dual HDMI input)
Two, HDCP-compliant digital video inputs.
2.
SLOT 2 (Dual HDMI input)
Two, HDCP-compliant digital video inputs.
SERIAL
PC IN
AUDIO
SLOT1
P
R
/C
R
/R
P
B
/C
B
/B
Y/G
AUDIO
R
L
COMPONENT/RGB IN
SLOT2
SLOT3
AV IN
A
B
AV IN
A
B
1
2
3
4
5
XP-50 / XP-OPAL50
XP-65 / XP-OPAL65
6
6
