Chapter 2
RuggedBackbone™ Modules
RuggedBackbone™ RX1510
Installation Guide
8
Ethernet - Fiber
Figure 7: 4TX04: 4 x 4-Pin 10/100TX M12
Section 2.3.2
Ethernet - Fiber
Figure 8: FX**/FG**: 2 × 100FX/1000SX/1000LX LC
Figure 9: 4FX**: 4 × 100FC LC
Figure 10: FX03: 2 × 100 FX MTRJ
Figure 11: 4FX03: 4 × 100FX MTRJ
Figure 12: FX**: 2 × 100FX SC
Figure 13: FX**: 2 × 100FX ST
Figure 14: FL01: 3 × 10FL/100SX
