Renesas TM V.3.20A - Manual (Page 89)

89
4.4.6.1 Action Tab
Fig. 4-55 Environment Setup Dialog Box (Action Tab)
■ Restore window condition
Restores the window position the next time the TM starts.
■ Restore font
Restores the display font the next time the TM starts.
■ Auto set line mark
Automatically checks line marks when opening the editor from the Inspector.
■ Automatic update
When using the Inspector from the Project Bar, if the object has been updated or the project has been altered, this
function automatically loads the object to perform analysis with updated contents. Unless this function is checked
(turned on), a dialog box is displayed for your confirmation.
4.4.6.2 Preview Tab
Fig. 4-56 Environment Setup Dialog Box (Preview Tab)
■ Tab size
Sets the preview window's display tab width. The tab size can be set in the range of 0 to 64.
■ Display color
Sets the colors in which to display the keywords and comments on the preview window.
